Main-
Head Info
te-
nance
GL2 Replot
GL2 BufferClear
GL2 Quali- Color
Set- ty Mode
tings Man-
ager
Print Quality
Input Resolution
Print (Economy)
Paper Paper Source
Man-
Margin
ager
Conserve Paper
Auto Rotate
Line & Enable merge
Pen
Man-
ager
Pen
Setup
iPF650
Setting Item
Monochrome
Color (CAD) 1
Color (CAD) 2
Color (CAD) 3
Color (CAD) 4
Color (CAD) 5
Select Palette
Printer Parts
Description, Instructions
Indicates information about the printhead.
Print the previous GL2 print job again.
Clear the print data in the replot buffer.
Print in monochrome.
Print in standard colors.
Print in brighter colors.
Print emulating the following printers, in colors re-
sembling colors produced by these printers: Canon
BJ-W3000/W3050.( *2
→P.667
Print emulating the HP Designjet 500/800, in colors
resembling colors produced by these printers.
( *2 )
→P.667
Print emulating the HP Designjet 1000, in colors re-
sembling colors produced by this printer.
( *2 )
→P.667
Choose the print quality.
Choose the printer input resolution, 600dpi or
300dpi.
Although printing quality is diminished, less ink is
consumed than in regular printing. Select On to con-
serve ink.
Choose the source of paper for HP-GL/2 printing.
Specify the margin around paper. The margin for the
trailing edge of sheets is 23 mm (0.9 in).
However, if you have specified the leading margin in
Paper Details, the value in Paper Details has priori-
ty.
Conserves paper when printing.
If the long side of an original is shorter than the roll
width, the original is automatically rotated 90 degrees
to conserve paper. Similarly, if the long side of an
original in landscape orientation is longer than the
roll width and the short side is shorter than the roll
width, the original is repositioned to fit on the paper.
HP RTL print jobs are not rotated. Because HP RTL
images are not rotated even if the paper is rotated 90
degrees, images may be cut off or the blank paper
may be ejected. In this case, set Auto Rotate to Off.
Specify whether to merge or print over colors where
lines overlap.
Choose Off to print the second line over the first.
Choose On to merge all overlapping colors.
As pen values, choose Software, Palette A, Palette
B, or Factory.
