1
1
S
ETTING UP THE
R
EMOVING THE
C
HECKING
The jukebox is shipped with a plastic bracket inserted into the mailslot to prevent damage to the mailslot during ship-
ping. A shipping screw is installed through the bottom of the chassis to restrain the cartridge picker.
NEXT
To remove the mailslot bracket, do the following. Refer to
1. Grasp both sides of the bracket and at the same time hook your fingers underneath its lower edge.
PREVIOUS
2. Gently bend the bottom of the bracket out slightly and while jiggling the bracket, pull it out from the mailslot.
JUMP
CONTENTS
INDEX
J
UKEBOX
M
AILSLOT
R
EMOVAL OF THE
S B
HIPPING RACKET AND
S S
HIPPING
Figure 1-2 on the following page.
CREW
6
