HP Surestore 125ex - Optical Jukebox Manual page 16

1
1
S
ETTING UP THE
The numbers below correspond to the numbers in
Table 1-1:
1
2
NEXT
PREVIOUS
JUMP
3
CONTENTS
INDEX
J
UKEBOX
Power receptacle Used to connect the power cord to the jukebox.
Standby/on switch The ON position applies power to the robotics and
electronics in the jukebox. The STANDBY
position removes power from the robotics and
electronics of the jukebox but power remains ON
inside the power supply enclosure on the rear of the
jukebox.
To remove power completely from the jukebox,
you must remove the power cable either from the
rear input on the jukebox or at the wall/floor
electrical outlet.
SCSI ports Two 68-pin high-density connectors that allow
connection to either a single-ended or low-voltage
differential SCSI bus. A terminator must be
plugged into one of these connectors when the
jukebox is the last physical device on a SCSI bus.
The terminator shipped with the jukebox is a
single-ended / low-voltage differential terminator.
For the most flexible configuration, use a self-
configuring single-ended / low-voltage differential
terminator (SE/LVD) even though the jukebox may
be originally configured onto a low-voltage
differential bus.
Figure 1-1 on the previous page.
5
