Remote Transmitter Description

The Astra 200 is supplied with Two 5-button Remote Transmitter used to control system
operations.
Button 1 Arms and Locks* the system and when held for 5 seconds, activates the system's Panic
feature. Button 1 also locks the doors when the system is in Valet Mode.
Button 2 Disarms and Unlocks* the system. Pressing Button 2 again operates the Passenger Unlock
feature (if installed). Button 2 also unlocks the doors when the system is in Valet Mode.
Button 3 Activates the Auxiliary 1 output. This output will remain on for as long as the button is
pressed.
Button 4 Activates the Auxiliary 2 output. This output will remain on for as long as the button is
pressed.
Button 5 is the Page Shift button. The Page Shift button will change the function of Buttons 1
through 4 each time it is pressed, allowing access to additional features or multiple car operation.
Each time the Shift Button is pressed, the LED on the transmitter will illuminate and the
transmitter functions will shift to the next page, allowing access to another set of features. Once
shifted to another page (there are 4 pages total), the transmitter will remain on that page for 10
seconds or until a button is pressed, then return to page 1. Each time a transmitter button is
pressed and held, the LED will flash a number of times to indicate from which page it is
transmitting. Under normal operation, only pages 1 and 2 are used. Pages 3 and 4 are usually
used for Two Car Operation (see page 3).
Shift then Button 1 Arms and Locks* the system silently.
Shift then Button 2 Disarms and Unlocks* the system silently.
* If the Optional Keyless Entry Feature is installed.
Page 6 - Astra 200

Remote Transmitters

Button 1
Button 3
LED
Button 2
Button 5
Button 4
