- Page 1 ASTRA 4000RS/1000RS-DBP SERIES VEHICLE SECURITY SYSTEM WITH REMOTE START PRODUCT MANUAL...
- Page 2 Limited Lifetime Warranty This vehicle security system is warranted to the original purchaser, to be free from defects in material and workmanship. The manufacturer will repair or replace at its option, and free of charge for the first twelve (12) months, any part that proves defective in material or workmanship under normal installation, use, and service, provided the product is returned to the manufacturer freight prepaid.
-
Page 3: Table Of Contents
About Your System ............Page 1 Remote Transmitters . -
Page 4: About Your System
The ScyTek ASTRA is a combination vehicle security and remote starting system. With proper installation this system will provide superior protection and performance for many years to come. The ASTRA/G55 built-in remote start feature is designed to offer maximum convenience by remote starting your vehicle’s engine, turning on the heater/air conditioner, and then running for a pre-determined time to provide a comfortable environment once you enter your vehicle. -
Page 5: Remote Transmitters
Standard Remote Transmitter Description Button 1 Button 3 The ASTRA/G55 comes equipped with the 5-button Remote Transmitters used to control system operations. Button 1 Arms the system and when held for 5 seconds, activates the system’s Panic feature. Button 1 also locks the doors when the system is in Valet Mode. -
Page 6: Adding/Replacing Transmitters
Adding/Replacing Transmitters To replace lost or stolen transmitters or to add additional transmitters into the system, have all desired transmitters ready and follow the steps below. Note: Up to 4 one-way transmitters can be programmed to operate the system. Any previously stored transmitter codes will be erased if they are not programmed within the following sequence. -
Page 7: Optional 2-Way Lcd Remote Transmitter Description
2-way LCD Remote Transmitter Description Button 1 The Astra 4000RS-2W-1 is supplied one 2-way LCD remote transmitter, offering increased range and confirmation of any activated features. Button 1 Arms the system and when held for 5 seconds, activates the system’s Panic feature. Button 1 also locks the doors when the system is in Valet Mode. -
Page 8: Lcd Transmitter Battery Replacement
LCD Transmitter Battery Replacement Your Astra Remote Transmitter uses a 1.5 volt AAA alkaline battery, which will require replacement in time. Depending on the amount of use, the battery may last up to three months before it needs replacement. When the battery needs replacing, the system’s operating range will decrease, the LCD display will show only one of three bars in the battery icon, or the display and sounds may suddenly stop and start as the battery voltage drops below minimum. -
Page 9: Lcd Backlight
4. When the desired time is displayed, press Button 5 to store. · The remote will play a melody to indicate the alarm clock has been set. To disable the automatic start / auto activate function: 1. Press and hold Buttons 2 and 3 until the remote beeps four times. ·... - Page 10 The PSV or passive function allows the passive arming mode to be enabled or with the transmitter. Note: This feature may not be available on all systems. To enable or disable the passive arming mode: 1. Press and hold Button 5 until the display shows PSV. ·...
-
Page 11: System Operation
Remote Arming The system monitors 5 independent areas ( zones ) while armed: doors, hood, trunk, shock sensor, optional sensor input, and the network port for future expansion. To Arm the System: 1. Turn off the ignition. 2. Press Button 1. ·... -
Page 12: Tamper Alert
Tamper Alert If the system was triggered while away, the LED will flash to indicate which zone triggered the system after disarming and turning on the ignition. The LED indication will repeat 8 times. LED Flashes (60 seconds): 1 flash 2 flashes 3 flashes 4 flashes... -
Page 13: Panic Mode
Panic Mode In the event of an emergency the transmitter’s remote Panic feature can be used to instantly trigger the alarm. To activate the Panic Mode: 1. Press and hold Button 1 for five seconds. · The alarm will sound. ·... -
Page 14: Automatic Rearming
To set the Emergency Override Code: 1. Turn on ignition. 2. Within 5 seconds, press the valet switch 5 times. · The siren will provide one long chirp, indicating that you have entered Programming. 3. Press the valet switch 6 times. ·... -
Page 15: Remote Start Feature
Remote Starting To Remote Start the System: 1. Be sure the system is not in Valet Mode. 2. Press and hold Button 4 for three seconds. · The parking lights will flash 4 times and turn on. · The Siren will chirp 4 times. ·... -
Page 16: Automatic Start Mode
Automatic Start Mode The Automatic Start Mode allows the vehicle to automatically start the vehicle every one or two hours and run for the preset Run Time. To turn on Auto Starting: 1. Turn Ignition switch Off and wait for 3 seconds. 2. -
Page 17: Extended Features
Ignition Door Locking For added safety, the Ignition Door Locking feature allows vehicles equipped with power door lock systems to automatically lock the doors when the ignition is turned on. If a door is open when the ignition is turned on, the Ignition Door Locking feature is disabled to protect against locking the keys inside the vehicle. -
Page 18: System Installation
1. Thoroughly read and become familiar with the installation instructions before beginning the installation. 2. Review system contents: Main Unit Two 5-Button Remote Transmitters (4000RS) One 5-Button & One LCD Two-Way Transmitter (4000RS-2W-1) Siren Shock Sensor Harnesses 6-Wire starter harness/Relay Module •... -
Page 19: Mounting The Control Unit
Mounting the Control Unit The control unit must only be mounted in the interior of the vehicle. Do not mount the main unit in the engine compartment. Choose a mounting location that will not be easily accessible to a thief, and will not interfere with the operation of any vehicle components such as foot pedals, steering column, air vents, seat rails, etc. -
Page 20: System Wiring
6-Wire Starter Harness Pin 1 RED - A: Main Power Input A (+). Connect to the battery or constant power wire at the ignition switch with a minimum 30 Amp supply. Remove the fuse until the installation is complete and all wiring is checked. -
Page 21: Plug-In Connectors
Pin 13 GRAY: Auxiliary 1 Output (-) 500 mA. Connect to a relay for an optional feature such as trunk release, etc. This output may be programmed for momentary, timed, or latched operation. Pin 14 GREEN/WHITE: Brake Input (+). Connect to the wire that shows +12V when pressing the brake. The Green/white wire is a safety shutdown wire that must be connected. -
Page 22: Jumper Settings
Jumper Selection Carefully separate the top and bottom halves of the main unit case. Once the cover is removed, the parking light polarity jumper will be visible next to the parking light relay. Set the jumper for the correct polarity output as described below, then reassemble the main unit case. -
Page 23: System Programming
Entering System Programming The system programming is compatible with both the LCD transmitter or the standard AM transmitter. To enter System Programming: 1. Turn on ignition. 2. Within 5 seconds, press the valet switch 5 times. · The siren will provide three chirps, indicating that you have entered Programming. 3. -
Page 24: Branch Table
Branch Feature 1. Arm Mode 2. Auto Rearming Mode 3. Arming Chirps 4. Warn-Away Pager Report 5. Extended Parking Lights 6. Ignition Door Locking 7. Ignition Door Unlocking 8. Door Unlock Pulse 9. Door Lock Pulse Length 10. Passive Door Locking 11. - Page 25 locking and unlocking. Program to 3 seconds for vehicles equipped with vacuum door locking systems. 0.1 seconds for vehicles that roll windows up or down when lock/unlock output is at 1 second. 10. Passive Door Locking. Selects whether or not the system will automatically lock the doors during Passive Arming.
- Page 26 RPM Learn. Start the engine, enter Branch 21 and press Button 1 to learn the vehicle’s tach signal. The siren will chirp and the LED will flash once to confirm learning of the tach signal and entering Tach Monitor Mode. The siren will chirp four times and the LED will flash four times if the tach signal was not learned, engine sense mode will not be changed.
-
Page 27: Relay Diagrams
Relay Diagrams Positive Dome Light Activation Negative Dome Light Activation Positive Horn Honk Negative Horn Honk Negative Glow Plug Starter Defeat/Anti-Grind ASTRA/G55 - Page 24... -
Page 28: Door Lock Diagrams
Door Lock Diagrams Follow the diagrams below for connecting basic door lock systems. For Two Stage door lock systems (separately unlocks driver and passenger doors) see following pages. Negative Trigger Positive Trigger Green Blue Reverse Polarity Vacuum Adding Actuators Page 25 - ASTRA/G55... - Page 29 Two Stage Door Lock Diagrams The ASTRA/G55 can be wired for the Passenger Unlock output feature, allowing Two Stage Door Lock operation. When connected as shown below, disarming the system will unlock only the driver’s door. Pressing the Aux 1 button will unlock all doors. Two Stage Negative Trigger Aux 1 output (gray wire) Two Stage Positive Trigger(using inverter)
-
Page 30: System Diagnostics
Two Stage Door Lock Diagrams cont’d Two Stage Reverse Polarity Aux 1 output (gray wire) Two Stage Adding Actuators Aux 1 output (gray wire) Page 27 - ASTRA/G55... -
Page 31: Technical Information
FCC ID: OARRXAM2000 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation Starter doesn’t start and parking lights flash: 3 Times - Engine RPM not detected (check tach wire and/or perform tach learn procedure) -
Page 32: Wiring Diagram
Orange- Accessory out (-) Yellow- Ignition 1 out (-) Violet- Starter out (-) Brown- Ignition 2 out (-) Red- + 12Volt out (+) Starter Harness Green-Lock (-) Blue- Unlock (-) Bypass Module Port Valet Switch LED Light Antenna © ScyTek Electronics 2010 Wiring Diagram ASTRA Models Are Programmable As...
