To attach the controller
CAUTION
If you purchased the SMART Board for Flat-Panel Displays interactive whiteboard without the pen
tray, you must install a controller unit.
NOTE: Depending upon where and how the interactive whiteboard is mounted, you may need to
perform the following steps by touch due to reduced visibility.
1. Remove the thumbscrews from the back of the overlay. You need these thumbscrews for
step 3.
2. Slide the holes in the controller over the threaded posts on the overlay.
3. Attach the thumbscrews that you removed in step 1 to the threaded posts to hold the controller
to the overlay.
99-00667-00 B0
Don't connect the interactive whiteboard to the computer until after you've installed
SMART Board software. For more information, see page 5.
Thumbscrews
Threaded
Posts
Installing the Interactive Whiteboard
Controller
Thumbscrews
