NOTE: Depending upon where and how the interactive whiteboard is mounted, you may need to
perform the following steps by touch due to reduced visibility.
CAUTION
1. Remove the thumbscrews from the pen tray bracket. You need these thumbscrews for step 3.
2. Slide the holes in the pen tray over the threaded posts on the pen tray bracket.
3. Attach the thumbscrews you removed in step 1.
99-00667-00 B0
Don't connect the interactive whiteboard to the computer until after you've installed
SMART Board software. For more information, see page 5.
Thumbscrews
Threaded Post
Pen Tray
Installing the Interactive Whiteboard
Pen Tray Holes
Thumbscrews
