Statistics — The Ethernet and RMON statistics displayed for the
■
selected port are described in the following table.
Table 12 Port Statistics Summary Page - Field Description
Field
Octets Input
Octets Output
Unicast Input
Unicast Output
Discard Output
Error Input
Error Output
QLen Output
Multicast Input
Multicast Output
Broadcast Input
Description
The total number of octets received on the interface,
including framing characters.
The total number of octets transmitted out of the
interface, including framing characters.
The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were not addressed to a
multicast or broadcast address at this sub-layer.
The total number of packets that higher-level protocols
requested be transmitted, and which were not
addressed to a multicast or broadcast address at this
sub-layer, including those that were discarded or not
sent.
The number of outbound packets which were chosen to
be discarded even though no errors had been detected
to prevent their being transmitted. One possible reason
for discarding such a packet could be to free up buffer
space.
For packet-oriented interfaces, the number of inbound
packets that contained errors preventing them from
being deliverable to a higher-layer protocol. For
character- oriented or fixed-length interfaces, the
number of inbound transmission units that contained
errors preventing them from being deliverable to a
higher-layer protocol.
For packet-oriented interfaces, the number of outbound
packets that could not be transmitted because of errors.
For character-oriented or fixed-length interfaces, the
number of outbound transmission units that could not
be transmitted because of errors
The length of the output packet queue (in packets).
The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were addressed to a multicast
address at this sub-layer.
The total number of packets that higher-level protocols
requested be transmitted, and which were addressed to
a multicast address at this sub-layer, including those that
were discarded or not sent.
The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were addressed to a broadcast
address at this sub-layer.
