D-Link DWL-3500AP - AirPremier Wireless Switching 108G Access Point Administrator's Manual page 41

64-bit (40-bit secret key + 24-bit initialization vector (IV)), 128-bit (104-bit secret key + 24-
bit IV), or 152-bit (128-bit secret key + 24-bit IV) Shared Key for data encryption.
Key Management
Static WEP uses a fixed key
that is provided by the
administrator. WEP keys are
indexed in different slots (up to
four on the access point).
The client stations must have
the same key indexed in the
same slot to access data on the
access point.
Recommendations
Static WEP was designed to provide the security equivalent of sending unencrypted data
through an Ethernet connection; however, it has major flaws and does not provide the intended
level of security.
Therefore, Static WEP is not recommended as a secure mode. The only time to use Static
WEP is when interoperability issues make it the only option available to you, and you are not
concerned with the potential of exposing the data on your network.
When to Use IEEE 802.1X
IEEE 802.1X is the standard for passing the Extensible Authentication Protocol (EAP) over an
802.11 wireless network using a protocol called EAP Encapsulation Over LANs (EAPOL).
This is a newer, more secure standard than Static WEP.
Key Management
IEEE 802.1X provides
dynamically-generated keys
that are periodically refreshed.
There are different
keys for each station.
Recommendations
IEEE 802.1X mode is a better choice than Static WEP because keys are dynamically generated
and changed periodically. However, the encryption algorithm used is the same as that of Static
WEP and is therefore not as reliable as the more advanced encryption methods such as
Temporal Key Integrity Protocol
(WPA) or WPA2.
Additionally, compatibility issues may be cumbersome because of the variety of
authentication methods supported and the lack of a standard implementation method.
Therefore, IEEE 802.1X mode is not as secure a solution as
than using IEEE 802.1X mode is to use WPA Enterprise mode.
Encryption Algorithm
An RC4 stream cipher is used
to encrypt the frame body and
cyclic redundancy checking
(CRC) of each 802.11 frame.
Encryption Algorithm
An RC4 stream cipher is used
to encrypt the frame body and
cyclic redundancy checking
(CRC) of each 802.11 frame.
Unicast
(TKIP) and
4 Configuring Access Point Security
User Authentication
This protocol provides a
rudimentary form of user
authentication when the client
uses a shared key algorithm.
User Authentication
IEEE 802.1X mode supports a
variety of authentication
methods, like certificates,
Kerberos, and public key
authentication with a RADIUS
server.
AES-CCMP used in Wi-Fi Protected Access
WPA or WPA2. A better solution
Understanding Security on Wireless Networks 41
