A Adapter Specifications

HP NetRAID-1M Specifications

Parameter
Product Number
Card Size
Processor
Bus Type
PCI Edge Connector
Bus Data Transfer Rate
BIOS
Cache Configuration
Firmware
Nonvolatile RAM
Operating Voltage
SCSI Controllers
SCSI Data Transfer Rate
SCSI Bus
SCSI Termination
Termination Disable
Devices per SCSI Channel
SCSI Device Types
Supported
SCSI Channels
RAID Levels Supported
SCSI Connectors
Multiple Cards
Battery Backup
Specification
P3410A
6.875" x 4.2" (half length PCI)
Intel i960RM™ @ 100 MHz
PCI 2.1/2.2 - 32-bits @ 33 MHz
3 V or 5 V (Universal)
Up to 132-MB per second
HP NetRAID BIOS
32-MB SDRAM DIMM with ECC
1-MB flash ROM
32-KB of NVRAM for disk configuration space
5.00 V ± 0.25 V
QLogic ISP10160
Up to 160-MB/sec with Ultra3 drives; 80-MB/sec with Ultra2
drives; 40-MB/sec with Ultra drives
Low voltage differential or single-ended SCSI
Active
Automatic through cable detection
Up to 12 depending on SCSI mode and storage cabinet
Low voltage differential or single-ended SCSI disk drives
One
0, 1, 5,10, and 50
One 68-pin, high-density internal connector
One 68-pin, ultra-high-density external connector
Up to six HP NetRAID adapters per system
No battery
149
