Barcode/OCR Font Settings
Manual
Barcode/OCR Fonts .......................................................................................................2
Types of Barcode/OCR Fonts ..................................................................................... 2
Barcode/OCR Font Calling and Available Parameters ............................................ 3
Character Code List ......................................................................................................5
UPC/EAN .................................................................................................................... 5
Interleave25 ................................................................................................................ 6
Code39 ........................................................................................................................ 7
Codabar (NW-7) .......................................................................................................... 7
Code128 ...................................................................................................................... 8
Postnet (ZIP) ............................................................................................................. 11
MSI Plessy ................................................................................................................ 11
Sample of Barcode/OCR Font Use ...........................................................................12
Precautions for Use ....................................................................................................14
Important .................................................................................................................. 14
8-bit Code and Control Code .................................................................................... 14
Start/Stop/Check Digit ............................................................................................. 14
Caption ..................................................................................................................... 14
Advertisement
Table of Contents
Related Manuals for Konica Minolta bizhub 25
Summary of Contents for Konica Minolta bizhub 25
-
Page 1: Table Of Contents
Barcode/OCR Font Settings Manual Barcode/OCR Fonts .......................2 Types of Barcode/OCR Fonts ..................2 Barcode/OCR Font Calling and Available Parameters ..........3 Character Code List ......................5 UPC/EAN ........................5 Interleave25 ........................ 6 Code39 ........................7 Codabar (NW-7) ......................7 Code128 ........................8 Postnet (ZIP) ...................... -
Page 2: Barcode/Ocr Fonts
Barcode/OCR Fonts This manual provides descriptions for types of barcode, character code and samples of font usage, etc. for models equipped with the Barcode/OCR font option. The content of this manual assumes the reader has a basic understanding of barcodes and barcode standards. -
Page 3: Barcode/Ocr Font Calling And Available Parameters
Postnet (ZIP) Postnet (ZIP) is a barcode represented as postal code for the United States (ZIP code). The check digit is modulus 10. Postnet font consists of numerals (ASCII) contained within Framebars (*: Hex2A and }: Hex7C). Codabar (NW-7) Codabar (NW-7) is a barcode represented in numerals and symbols ($, +, -, ., /.). Most standards do not define a check digit. - Page 4 24631 EAN/JAN-13 +2 24632 EAN/JAN-13 +5 24640 Interleaved 2 of 5 24641 Interleaved 2 of 5 CHK 24670 Code 39 (3of9) 24671 Code 39 + CHK 24672 Code 39 (3of9) encode space before data 24673 Code 39 + CHK encode space before data 24702 Code 128 B 24704...
-
Page 5: Character Code List
Character Code List List the character codes used when assigning the Barcode Character. UPC/EAN A character code that is used when printing the Barcode Character for UPC/EAN. Character code Left side odd parity Left side even parity Right side even parity Character ASCII ASCII... -
Page 6: Interleave25
Interleave25 A character code that is used when printing the Barcode Character for Interleave25. Character code Character code Character code Character Character Character ASCII ASCII ASCII notation notation notation notation notation notation " & < > Start Stopp Note Assign two character sets for the bar character and space character by a single character code. -
Page 7: Code39
Code39 A character code that is used when printing the Barcode Character for Code39. Character code Character code Character code Character Character Character ASCII ASCII ASCII notation notation notation notation notation notation Codabar (NW-7) A character code that is used when printing the Barcode Character for Codabar (NW-7). Character code Character code Character code... -
Page 8: Code128
Code128 A character code that is used when printing the Barcode Character for Code128. Character Character code Numeric value Code A Code B Code C HEX notation ASCII notation " " " & & & < < < > > >... - Page 9 Character Character code Numeric value Code A Code B Code C HEX notation ASCII notation Character Code List...
- Page 10 Character Character code Numeric value Code A Code B Code C HEX notation ASCII notation FNC3 FNC3 FNC2 FNC2 SHIFT SHIFT CODE C CODE C CODE B FNC4 CODE B FNC4 CODE A CODE A FNC1 FNC1 FNC1 START (CODE A) START (CODE B) START (CODE C) STOP...
-
Page 11: Postnet (Zip)
Postnet (ZIP) A character code that is used when printing the Barcode Character for Postnet (ZIP). Character code Character HEX notation ASCII notation Framebar Framebar MSI Plessy A character code that is used when printing the Barcode Character for MSI Plessy. Character code Character HEX notation ASCII notation... -
Page 12: Sample Of Barcode/Ocr Font Use
Sample of Barcode/OCR Font Use The surrounding blank area and caption are not included in the following example. Escape code <ESC> and carriage return code <CR> are required for code value input. The value of nn is a hexadecimal digit for items listed as <Hexnn>. Input for the corresponding code is required. - Page 13 Codabar Data to be displayed A19+1243B (Check Digit :) <ESC>(5Y<ESC>(s12vbs24750TA1941243:B<CR> MSI Plessy Data to be displayed 1234567 (No Check Digit) <ESC>(6Y<ESC>(s12vbs24760T<1234567><CR> OCR-A Data to be displayed 12345ABCDE <ESC>(0O<ESC>(s12vbs104T12345ABCDE<CR> OCR-B Data to be displayed 12345ABCDE <ESC>(1O<ESC>(s12vbs110T12345ABCDE<CR> Sample of Barcode/OCR Font Use...
-
Page 14: Precautions For Use
Precautions for Use Important • This barcode can only be used with PCL5e. • In order to correctly print and use the barcode font, the application software must support the barcode font. • It may not be possible to read the printed barcode with all scanners due to variations in toner density and paper quality, therefore we recommend that you verify the reading ability of the scanner before use.
