How to operate the AUDIO CONTROL
Switching audio control modes
Various audio control modes may be fine-tuned using this procedure.
Press the [AUDIO CONTROL] button for less than one second to select the item
1
to be adjusted.
Modes will switch in the order shown below each time the button is pressed.
VOL ➔ BASS ➔ MID ➔ TREB ➔ BAL ➔ FAD ➔ NON-F*
➔ VOL
*1: NON-F (non-fader) Output is not affected by the settings of the BASS, MID,
TREBLE, loudness function or equalizer.
*2: Setting cannot be made in FM mode.
ATTENTION
Press the [MUTE] button for less than one second to cut the volume or restore it instantly.
WARNING
Do not adjust the volume or other controls while driving the vehicle. Do so only while parked in a
safe location.
Mode
VOL (VOLUME)
BASS
MID (MIDDLE)
TREB (TREBLE)
BAL (BALANCE)
FAD (FADER)
NON-F (NON-FADER)
Function
Adjusts volume.
AAdjusts bass level. Bass mode can be
adjusted for each source
(CDP/CDC, FM ,AM(MW) and LW).
Adjusts middle level. Mid mode can be
adjusted for each source
(CDP/CDC, FM , AM(MW) and LW).
Adjusts treble level. Treble mode can be
adjusted for each source
(CDP/CDC, FM , AM(MW) and LW).
Adjusts left/right speaker balance.
Adjusts front/rear speaker balance.
Adjusts non-fader level (for connected
sub-woofers, etc.).
How to operate the AUDIO CONTROL
1
[AUDIO CONTROL] button
Turn to the Right
Increases the volume.
Emphasizes low
sounds.
Emphasizes medium
sounds.
Emphasizes high
sounds.
Emphasizes right
speakers.
Emphasizes front
speakers.
Increases level.
107
2
➔ SVC*
➔ LOUD
Turn to the Left
Decreases the
volume.
Softens low sounds.
Softens medium
sounds.
Softens high sounds.
Emphasizes left
speakers.
Emphasizes rear
speakers.
Decreases level.
IX
X
