Various Settings

How to operate the AUDIO CONTROL

Switching audio control modes

Various audio control modes may be fine-tuned using this procedure.
1
Press the [ENTER] button to select the item to be adjusted.
Modes will switch in the order shown below each time the button is pressed.
BASS → MID → TREB → BAL FAD → NON-F*
*1: Setting cannot be made in FM mode.
*2: NON-F (non-fader) Output is not affected by the settings of the BASS, MID and
TREBLE.
WARNING
Do not adjust the volume or other controls while driving the vehicle. Do so only while parked in a
safe location.
Mode
BASS Adjusts bass level.
MID
Adjusts middle level.
(MIDDLE)
TREB
Adjusts treble level.
(TREBLE)
Adjusts different volume levels for
each audio mode. When SVC is set,
SVC the volume level can change as
shown in the example setting (See
next page).
BAL/FAD
Adjust left/right (BALANCE) and
(FADER/
front/rear (FADER) speaker balance.
BALANCE)
NON-F
Adjusts non-fader level (for
(NON-FADER
connected sub-woofer).
LEVEL)
The loudness control may be turned
on the emphasize low and high
frequencies at low volume levels.
LOUDNESS Loudness compensates for the
apparent weakness of low and high
frequencies at low volume by
boosting the bass and treble levels.
38
Function
Emphasizes
low sounds.
Emphasizes
medium
sounds.
Emphasizes
high sounds.
Increase the
SVC setting
level.
Emphasizes
front
speakers.
Increase the
sub-woofer
level.
Select ON
2
→ LOUD → SVC*
Button operation (Press [SELECT] button)
Upper Lower
Softens low
sounds.
Softens
medium
sounds.
Softens high
sounds.
Decrease the
SVC setting
level.
Emphasizes
rear
speakers.
Decrease the
sub-woofer
level.
Select OFF
1
→ BASS
Right Left
- -
- -
- -
- -
Emphasizes
Emphasizes
right
left speakers.
speakers.
- -
- -
