4. Trouble Shooting

This section will guide you to solve abnormal situations. Please follow the
below steps to check your basic installation.
Step 1.

Is the Hardware Status OK?

1. Check the power line and WLAN/LAN cable connections. Refer
to the Quick Start Guide "2.1 Hardware Installation" section for
details.
2. Turn on the router, check if the ACT LED blink once per second
and the correspondent LAN LED is bright.
Step 2.

Are the Network Connection Settings on Your PC OK?

The following example is based on Windows XP case. Regarding to
the examples of other OSs, please refer to the similar steps or find
support notes in www.draytek.com.
1. Go to Control Panel and then double-click on Network
Connections.
2. Right-click on Local Area Connection and click on Properties.
19
