To The Remote Tv - Dish Network DuoDVR ViP 722_TOC User Manual

1
Pressing MENU, then select System Setup, Installation, and then
Phone System.
2
Select the Touch Tone or the Rotary Phone option in the Phone Type list.
3
Select either the No Prefix or the Prefix Code option in the Outside Line Prefix list.
Note: Usually, you need a telephone number prefix only for business installations. For
most residential installations, all you need to do is set the telephone system type. The
default setting of No Prefix will allow correct dialing. If this is the case, select the Save
option to save the above setting, and stop here. If you do need to set a prefix, then instead
of selecting the Save option, go on to step 5.
4
If you selected No Prefix, select Done.
5
If you selected Prefix Code, the receiver highlights the box where you must enter the
exact sequence you dial the phone to obtain an outside line.
6
Select Done.
C
ONNECTING A
The diagram below provides example of how to connect VCRs to your satellite TV system.
For this installation, always leave your VCR powered on so that the TV can
receive satellite programming. If you turn off your VCR, your TV will not be
tuned to the correct channel to receive satellite programming.
Note: Connecting your TV directly to the satellite receiver provides the best audio and
video quality.
VCR R
TO THE EMOTE
Remote TV
OUT
Coaxial Cable
IN
Coaxial Cable
IN
Wall
Connections and Setup
Connecting a VCR to the Remote TV
TV
109
