4 ON-SCREEN/MENU SWITCHES
4-7 Contents of Menu Switches
[ ]: Factory setting • The lower section in the items and set values columns shows what's on the VCR's display.
Screens Items
DURATION
ALARM/
SENSOR
MODE
(VCR's display)
AL SE 3
TAPE END
MODE
AL SE 4
BUZZER TAPE END
BU 22 1
AL/SENSOR
IN
BU 22 2
WARNING
BU 22 3
IN/OUT CAMERA SW
iO
RS-232C
B. RATE
iO
26
Set values
5 SEC Selects the recording duration for alarm or sensor recording.
10 SEC
5 — 180 SEC: Alarm or sensor recording is performed for the specified
15 SEC
30 SEC
TAPE END: Alarm or sensor recording continues to the end of the tape.
60 SEC
MANUAL:
120 SEC
[180 SEC]
TAPE END
MANUAL
5
. .
.
180
TPEN
NANU
[OFF] Selects whether or not the Stop mode is forcibly engaged when the tape
ends even if there is an alarm or sensor recording.
STOP
OFF: The forced Stop mode is not engaged.
OFF
STOP
STOP: The Forced Stop mode is engaged.
[OFF] Sets whether or not the buzzer sounds when the tape ends in the
Record mode.
ON
OFF: The buzzer does not sound.
OFF
ON: The buzzer sounds when the tape ends during recording. Also, the
ON
[OFF] Selects whether or not the buzzer sounds during alarm or sensor
ON recording.
OFF: The buzzer does not sound.
OFF
ON: The buzzer sounds.
ON
[OFF] Sets whether or not the buzzer sounds when a warning occurs.
ON OFF: The buzzer does not sound.
ON: The buzzer sounds. When the warning is released, the buzzer
OFF
ON
[OFF] Sets the camera switching signal output interval.
1 FIELD OFF:
2 FIELD 1 FIELD: Set to this position to switch cameras every 1 field.
2 FIELD: Set to this position to switch cameras every two fields (1
1 OFF
1FRD
2FRD
This screen is shown only when the optional SA-K97U RS-232C board is installed.
600
1200 Selects the RS-232C data transfer rate (600 bps, 1200 bps, 2400 bps,
2400
4800 bps and 9600 bps).
4800
[9600]
600
3 . .
.
9600
Function
time (5 sec. to 180 sec.)
Alarm or sensor recording continues for as long as alarm
signals are input. Set to this position when specifying the
alarm recording time with a switcher.
*To ensure accurate alarm search and alarm scan operation,
be sure to set the recording time to 5 seconds or more.
• When the tape ends, the mode set with the menu switch <AUTO
REW> or <REPEAT REC> on the <VTR MODE> screen is engaged.
buzzer sounds when the tape reel counter value set with the menu
switch <CNT TAPE END> on the SRI/EXT MODE screen is reached.
When the mode is changed by pressing the [REW] button,
[EJECT] button or [OPERATE] button, the buzzer sound stops.
sound stops.
No camera switching signal is output.
frame).
