System Requirements - Kodak I810 - Scanner Firmware - PC Installation Planning Manual

System
requirements
A-61176 November 2001
This section lists the host requirements for the i800 Series Scanners.
The following minimum software and hardware requirements for an i800
Series Scanner is needed to achieve duplex, single-stream throughput
(bi-tonal) at rated speed.
Operating Systems: Windows 98, Millennium, NT, 2000, XP
Single Processor PC
Pentium 2 400 MHz CPU
128 MB of RAM (memory)
29160 SCSI Adapter or equivalent (Ultra2 Wide SCSI support, with
transfer rates up to 80 MB/sec) dedicated to scanner, configured for
Synchronous Data Transfers (80MB/sec)
The recommended software and hardware requirements for an i820/840
Series Scanner are:
Operating Systems: Windows 98, Millennium, NT, 2000, XP
Single Processor PC
Pentium 4 1.5 GHz CPU
512 MB of RAM (memory)
29160 SCSI Adapter or equivalent (Ultra2 Wide SCSI support, with
transfer rates up to 80 MB/sec) dedicated to scanner, configured for
Synchronous Data Transfers (80MB/sec)
29160 SCSI card or equivalent for SCSI hard drives (Ultra2 Wide
SCSI support)
2 hard drives: one for the operating system and one for the data (i.e.,
scanned images). The second drive should be 60GB for storing
image data.
AGP (Advanced Graphics Processor) Video Card with 32MB of video
RAM, supporting Direct X
The recommended requirements for the i820/840 are needed to achieve
dual-stream at the rated throughput.
Testing was done with Kodak's Scan Validation Tool using 200 dpi color
and 200 dpi bi-tonal dual stream duplex, letter/A4/landscape while
viewing every image. Both the TWAIN Data Source and ISIS Driver
were tested.
For PCs running Windows 2000 or Windows XP using Adaptec SCSI
cards, reference the Adaptec website (www.adaptec.com) for the most
up-to-date version of the SCSI device driver.
SCSI host adapter BIOS should be set to "Disabled: scan bus".
7
