Chapter 5 Troubleshooting SAN Switching Issues
S e n d d o c u m e n t c o m m e n t s t o n e x u s 5 k - d o c f e e d b a c k @ c i s c o . c o m .
Well Known Address
x'FF FF FB'
x'FF FF FC'
x'FF FF FD'
x'FF FF FE'
x'FF FF FF'
Fibre channel port remains in initializing state
A fibre channel F type port does not come online and is stuck in an initializing state.
The show interface fc <slot/port> command displays the following message.
A Fibre Channel port goes into the initialization state after a successful completion of link-level
initialization. For F type ports, the next step is to complete the FLOGI (fabric login) process. The port
remains in the initialization state until the FLOGI process completes.
Possible Cause
The port is up because the link partner has put itself into a bypass mode.
Solution
Use the show hardware internal fc-mac <slot-number> port <port-number> statistics command to
check whether the Class-3 input counter is increasing after the successful completion of link
initialization.
Example:
switch# show hardware internal fc-mac 2 port 1 statistics
ADDRESS
__________ ________
0x0000003c FCP_CNTR_MAC_RX_LOSS_OF_SYNC
0x0000003d FCP_CNTR_MAC_RX_BAD_WORDS_FROM_DECODER
0x00000042 FCP_CNTR_MAC_CREDIT_IG_XG_MUX_SEND_RRDY_REQ
0x00000043 FCP_CNTR_MAC_CREDIT_EG_DEC_RRDY
0x00000061 FCP_CNTR_MAC_DATA_RX_CLASS3_FRAMES
0x00000062 FCP_CNTR_MAC_DATA_RX_CLASSF_FRAMES
0x00000069 FCP_CNTR_MAC_DATA_RX_CLASS3_WORDS
0x0000006a FCP_CNTR_MAC_DATA_RX_CLASSF_WORDS
0x00000065 FCP_CNTR_MAC_DATA_TX_CLASS3_FRAMES
0x00000066 FCP_CNTR_MAC_DATA_TX_CLASSF_FRAMES
0x0000006d FCP_CNTR_MAC_DATA_TX_CLASS3_WORDS
0x0000006e FCP_CNTR_MAC_DATA_TX_CLASSF_WORDS
0xffffffff FCP_CNTR_LINK_RESET_IN
0xffffffff FCP_CNTR_OLS_IN
0xffffffff FCP_CNTR_NOS_IN
0xffffffff FCP_CNTR_LRR_IN
0xffffffff FCP_CNTR_LINK_RESET_OUT
0xffffffff FCP_CNTR_OLS_OUT
0xffffffff FCP_CNTR_NOS_OUT
0xffffffff FCP_CNTR_LRR_OUT
0xffffffff FCP_CNTR_LINK_FAILURE
Possible Cause
The FLOGI packet was dropped somewhere in the data path, starting from FC-MAC to FLOGI server.
OL-25300-01
Description
Time Service (FC-GS-5)
Directory Service (FC-GS-5)
Fabric Controller
F_Port Controller
Broadcast Address/Server
fc slot/port is down (Initializing)
STAT COUNT
__________________
Cisco Nexus 5000 Series Troubleshooting Guide
FC Services
0x1
0x50
0x152
0x7c
0x130
0x22
0x61c98
0xff0
0x52
0x2a
0x944c
0xec4
0x1
0x1
0x1
0x2
0x1
0xa
0x2
0xb
0x2
5-17
