Chapter 4 Troubleshooting QoS Issues
S e n d d o c u m e n t c o m m e n t s t o n e x u s 5 k - d o c f e e d b a c k @ c i s c o . c o m .
Command
show plat soft
redwood rmon 4 nif1
show plat soft
redwood rmon 4 hif5
show plat soft
redwood ss
show plat soft
redwood ss 4 3
show plat soft
redwood ss 4 2
show plat soft
redwood rate
show plat soft
redwood rmon 6 cif0
show plat soft
qosctrl port 0 6 cif
0 counters
Nexus 5000 multicast-optimization
Use the following commands:
Nexus 5000 FCoE classification
•
•
Nexus 5000 MTU programming
Use the following command:
show hardware internal gatos asic 0 registers match bm_port_CFG.*_max
Nexus 5000 interrupt
Use the following commands:
debug hardware internal gatos asic 0 clear-interrupt
OL-25300-01
Purpose
Displays statistics of MAC level traffic and pause statistics of iNIF for
eth103/1/37.
Displays statistics of MAC level traffic and pause statistics of HIF for
eth103/1/37.
Displays mapping of HIF/NIF to SS.
Displays statistics of RW4 SS3 - Host Receive from HIF4-7 to NIF0-3
Displays statistics of RW4 SS2 - Host Receive from HIF0-3 to NIF0-3
Displays overall statistics for non-zero traffic.
Helps debug traffic going from CIF to CPU.
Helps debug traffic going from CIF to CPU.
show plat fwm in mco-info
show plat fwm in vlan 1 all_macgs
For the FCoE interface, use the following commands:
show plat fwm info pif ethernet 1/1 | grep gatos
debug platform hardware peek lu 7 index 5 pifTable
For the FC interface, use the following commands.
(The first command is used to get the gatos number and the fc number.)
show platform fwm info pif fc <id>
debug peek lu <gatos> index <fc num> pifTable
Cisco Nexus 5000 Series Troubleshooting Guide
Registers and Counters
