VLANs
S e n d d o c u m e n t c o m m e n t s t o n e x u s 5 k - d o c f e e d b a c k @ c i s c o . c o m .
QoS
Network QoS (MTU)
Network Qos (Pause)
Input Queuing (Bandwidth)
Input Queuing (Absolute
Priority)
Output Queuing (Bandwidth)
Output Queuing (Absolute
Priority)
STP Mode
STP Disabled
STP MST Region Name
STP MST Region Revision
STP MST Region Instance to
VLAN Mapping
STP Loopguard
STP Bridge Assurance
STP Port Type, Edge
BPDUFilter, Edge BPDUGuard
STP MST Simulate PVST
Allowed VLANs
Local suspended VLANs
switch#
Configuring interface to access port does not allow VLAN <###> to go through
After configuring an interface to access a port for allowing VLAN <###>, the VLAN <###> does not go
through.
Possible Cause
The VLAN was not created.
Solution
In NX-OS, configuring with the switchport access vlan <###> command on an interface does not
automatically create VLAN <###>. You must specifically create VLAN <###> using the vlan <###>
command. Use the show vlan command to determine if VLAN <###> exists. If it does not exist, then
use the vlan <###> command to create the VLAN.
Cannot create VLAN
The VLAN cannot be created.
Possible Cause
All VLAN resources are exhausted.
Solution
For the Nexus 5000, the maximum number of active VLANs and VSANs per switch is 512 (31 reserved
for VSAN; remainder reserved for VLAN). Use the show resource vlan command to determine the
number of available VLANs.
Example:
switch(config)# show resource vlan
Cisco Nexus 5000 Series Troubleshooting Guide
3-8
1 ([], [3], [], [], [],
[])
1 (1538, 2240, 0, 0, 0,
0)
1 (F, T, F, F, F, F)
1 (50, 50, 0, 0, 0, 0)
1 (F, F, F, F, F, F)
1 (50, 50, 0, 0, 0, 0)
1 (F, F, F, F, F, F)
1 Rapid-PVST
1 None
1 ""
1 0
1
1 Disabled
1 Enabled
1 Normal, Disabled,
Disabled
1 Enabled
- 1-2
2
Chapter 3 Troubleshooting Layer 2 Switching Issues
([], [3], [], [], [],
[])
(1538, 2240, 0, 0, 0,
0)
(F, T, F, F, F, F)
(50, 50, 0, 0, 0, 0)
(F, F, F, F, F, F)
(50, 50, 0, 0, 0, 0)
(F, F, F, F, F, F)
Rapid-PVST
None
""
0
Disabled
Enabled
Normal, Disabled,
Disabled
Enabled
1-2
-
