vi
mdwin
mdwin0
inter
weekday
begintime
endtime
action_do_i<0~(ndo-1)>
_enable
action_do_i<0~(ndo-1)>
_duration
action_wled_i<0~(nwled-
1)>_enable
action_wled_i<0~(nwled-
1)>_duration
action_server_i<0~4>_en
able
action_server_i<0~4>_m
edia
<integer> 6/6
<integer> 6/6
<integer> 6/6
1~999 6/6
0~127 6/6
hh:mm 6/6
hh:mm 6/6
0, 1 6/6
1~999 6/6
0, 1 6/6
1~999 6/6
0, 1 6/6
NULL, 6/6
0~4,101
Indicate the source id of vi trigger.
This field is required when trigger condition is "vi".
One bit represents one digital input. The LSB
indicates VI 0.
Indicate the source window id of motion detection.
This field is required when trigger condition is "md".
One bit represents one window.
st
The LSB indicates the 1
For example, to detect the 1
mdwin as 5.
Similar to mdwin. The parameter takes effect when
profile 1 of motion detection is enabled.
Interval of snapshots in minutes.
This field is used when trigger condition is "seq".
Indicate which weekday is scheduled.
One bit represents one weekday.
bit0 (LSB) = Saturday
bit1 = Friday
bit2 = Thursday
bit3 = Wednesday
bit4 = Tuesday
bit5 = Monday
bit6 = Sunday
For example, to detect events on Friday and Sunday,
set weekday as 66.
Begin time of the weekly schedule.
End time of the weekly schedule.
(00:00 ~ 24:00 sets schedule as always on)
Enable or disable trigger digital output.
Duration of the digital output trigger in seconds.
Enable or disable trigger white light LED.
Duration of the white light LED trigger in seconds.
Enable or disable this server action.
Index of the attached media.
101: recording notify
VIVOTEK
window.
st rd
and 3 windows, set
User's Manual - 143
