The case is released and can
be removed.
Installing cases
Pull the case handle up as far
as it will go.
Seat the case in top holders 4
and in holder 5 at the rear
footrest.
Push handle 3 down until it
engages.
Turn the key in the case lock
to the LOCK position and re-
move the key from the lock.

Topcase

with topcase, small OA
Opening topcase
Turn the key to the OPEN pos-
ition in the topcase lock.
Push lock barrel 1 forward.
Lever 2 pops up.
