BMW R 1200 R CLASSIC Rider's Manual page 107

There is a risk of mixing up
the full-beam headlight bulb
and the low-beam headlight bulb
when installing the bulb sockets.
Note the colour-coding of the
wires for the low-beam headlight
(yellow) and the high-beam head-
light (white).
Turn bulb socket of low-beam
headlight 1 or high-beam
headlight 2, as applicable,
clockwise to install. Make
sure that the colour coding of
the wire is correct: low-beam
headlight=yellow.
Installing headlight in housing
( 108).
Replacing parking-light
bulb
Remove the headlight (
Remove bulb socket 1 from
the housing.
107).
Remove bulb 2 from bulb
socket 1.
Replace the defective bulb.
Bulb for parking light
W5W / 12 V / 5 W
