8
108
Remove screw 1.
Ease cover 2 forward to re-
move.
z
Remove screw 3.
Work the headlight forward and
out of the housing.
Installing headlight in
housing
Position the headlight in the
housing.
Install screw 3.
Install cover 2; make sure that
tabs 5 of the cover engage the
corresponding holders.
Install screw 1.
