Push the protective cap over
4
the threaded fastener.
48

Spring preload

Setting
It is essential to set spring pre-
load of the rear suspension to
suit the load carried by the mo-
torcycle. Increase spring preload
when the motorcycle is heavily
loaded and reduce spring preload
z
accordingly when the motorcycle
is lightly loaded.
Adjusting spring preload
for rear wheel
Remove the seat (
Your motorcycle's hand-
ling will suffer if you do not
match the spring-preload and
damping-characteristic settings.
Adjust the damping characteristic
to suit spring preload.
If you want to increase spring
53).
preload, turn knob 1 in the dir-
ection indicated by the HIGH
arrow.
If you want to reduce spring
preload, turn knob 1 in the dir-
ection indicated by the LOW
arrow.
Basic setting of spring
preload, rear
without Electronic Suspen-
sion Adjustment (ESA)
Knob set to "STD" on the
scale at the side (Full load of
fuel, with rider 85 kg)
Installing seat ( 54).
