Instrument panel

1 Speedometer
2 Warning and telltale lights
( 22)
3 Rev. counter
4 Ambient-light brightness
sensor (for adapting the
brightness of the instru-
ment lighting)
with anti-theft alarm
Anti-theft alarm telltale light
(see the instructions for
use for the anti-theft alarm)
5 Operation of the clock
( 39)
6 Multifunction display
( 20)
7 Control for the odometer
( 40)
