8
Silencer to rear frame
100
19 Nm
z
Slip the clamp forward as far as
it will go and turn it so that R/
RT mark 3 on the clamp is in
line with mark 4.
Tighten screw 1 to the spe-
cified tightening torque.
Clamp to silencer and
manifold
28 Nm

Front-wheel stand

Install the front-wheel
stand
Make sure the ground is level
and firm and place the motor-
cycle on its centre stand.
Use basic stand with tool num-
ber (83 30 0 402 241) in com-
bination with front-wheel ad-
apter (83 30 0 402 242).
Slacken adjusting screws 1.
Push the two adapters 2 apart
until the front forks fit between
them.
Use locating pins 3 to set the
front-wheel stand to the de-
sired height.
Centre the front-wheel stand
relative to the front wheel and
push it against the front axle.
