Install bulb 2 in bulb socket 1.
z
Install bulb socket 1 in the
housing.
Installing headlight in housing
(
108).
Replacing brake light and
rear light bulb
The steps in the procedure
described here also apply
by analogy to a motorcycle with a
luggage carrier.
Remove the seat (
Remove screws 1.
Work the tail cover forward to
remove.
Switch off the ignition.
53).
Remove screw 1.
Work the bulb housing to the
rear to remove.
Turn bulb socket 2 counter-
clockwise to remove it from the
housing.
