AIR CLEANER SAFETY
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
Air Purifier
INSTRUCTIONS
BAP414-CN
MODEL :
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons, including the following:
1. Read all instructions before using appliance.
2. To avoid fire and shock hazard, plug the appliance
directly into a 120V AC electrical outlet.
3. If the filter is covered by a bag when shipped: remove
plastic bag before use.
4. Keep the cord out of heavy traffic areas. To avoid fire
hazard NEVER put the cord under rugs, near heat
registers, radiators, stoves or heaters.
5. To protect against electrical hazards DO NOT immerse
in water or other liquids. Do not use near water.
6. Close supervision is necessary when any appliance is
used by, or near children or by disabled persons.
7. Always unplug the air purifeir before moving it,
opening the grill, changing the filters or whenever the
air purifier is not in use. Unplug by pulling on the plug
and not the cord.
8. NEVER drop or insert any object into any openings.
9. Do not operate any appliance with a damaged cord or
plug, if motor fan fails to rotate, after the appliance
malfunctions, or if it has been dropped or damaged in
any manner. Return appliance to manufacturer for
examination, electrical or mechanical adjustment or
repair.
10.Use appliance only for the intended household use as
described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock or injury to persons. The use of
attachments not recommended or sold by the
manufacturer may cause hazards.
11.Do not use outdoors.
Read instructions before operating. 12.Never block the air openings, or place on soft surface,
Retain for future reference. such as bed or sofa, as this could cause the unit to
tip over thus blocking the air intake opening.
Instruction Leaflet
13.Keep unit away from heated surfaces and open
☎ flames.
INFO-LINE
14.DO NOT attempt to repair or adjust any electrical or
If after having read this leaflet, you have any
mechanical functions on this unit. Doing so will void
questions or comments on your air cleaner, the warranty. The inside of the unit contains no user
call 1-800-253-2764 in North America.
serviceable parts. All servicing should be performed
128311/9100040003400
by qualified personnel only.
TROUBLESHOOTING
Problem Solution
Unit will not operate Check to make sure unit is
properly plugged in.
Check to make sure the unit is
on by sliding or rotating the
power switch to the ON
position.
Decreased air flow Check the filter to see if it is in
good condition and if it needs
to be changed.
Check to ensure nothing is
blocking air inlet and filtered air
outlet.
15.WARNING: To reduce the risk of fire or electrical Finally, using your ionizer may result in an occasional
shock, DO NOT use this air purifier with any solid- popping or cracking sound. This is a normal sound,
state speed control device. generally caused by a small build-up of ions that, when
discharged, cause the popping or cracking sound.
16.DO NOT place anything on top of the unit.
NOTE: It is important to replace the HEPA-Type filter at
PLEASE SAVE THESE
the recommended intervals.
INSTRUCTIONS Using the ionizer in conjunction with dirty filters may result
in dirty particles exiting the air purifier and being attracted
to walls, carpets, furniture or other household objects.
CONSUMER SAFETY INFORMATION
These dirty particles may prove very difficult to remove.
THIS APPLIANCE HAS A POLARIZED Homes with excessive amounts of pet dander, dust, or
PLUG (one blade is wider than the other). smoke may decrease the life expectancy of the HEPA-
Type filtration system and may interfere with the ionization
To reduce the risk of electric shock, this
plug is intended to fit in a polarized outlet process. You may want to run the Ionizer less often and
only one way. If the plug does not fit fully check the condition of the HEPA-Type filter(s) more
frequently in order to reduce particles from being
in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician attracted to surfaces throughout your home as
to install the proper outlet. mentioned above.
DO NOT DEFEAT THE SAFETY PURPOSE OF THIS PRE-OPERATING INSTRUCTIONS
POLARIZED PLUG IN ANY WAY.
1. Carefully unpack your Air Purifier. Select a firm, level
place where there are no obstructions to the air inlet
The length of the cord used on this product was selected
or filtered air outlet. A good location in a room is
to reduce the hazards of becoming tangled in, or tripping
over a longer cord. If a longer cord is necessary an approximately 1 foot away from the wall, in a central
location of your home.
approved extension cord may be used. The electrical
rating of the extension cord must be equal to or greater
2. Remove the air inlet grill by grasping the finger tabs on
than the rating of the air cleaner (refer to the rating label
both sides.
placed on the air purifier). Care must be taken to arrange
3. Remove the HEPA-Type filter by gripping on both
the extension cord where it cannot be pulled on by
sides and pulling forward.
children or accidentally tripped over.
4. Remove protective plastic bag from the filter cartridge.
IONIZER
5. This model utilizes hang tabs and a filter clip. The clip
Your Air Purifier has an independently controlled ionizer,
can only be attached to the tabs on the filter in only
which, when turned on, releases negative ions into
one way. The filter clip should easily slide onto the
outgoing filtered air. Ions are tiny particles that carry a
filter hang tab with only a small amount of pressure.
positive or negative charge. These ions exist naturally
DO NOT use force while attaching the clip to the filter.
around us, in the air, water and ground. Both positive and
Align the clip on the top of the HEPA-Type filter with
negative ions are colorless, odorless and completely
the rails on the inside of the purifier unit. Gently slide
harmless. Negative ions help the air purification process
the filter onto the rail (Figure 1).
by attaching themselves to very small airborne particles in
NOTE: The side with
the room.
the soft gasket should
These particles take on a negative charge and may join
face inward.
with positively charged particles such as dust, pollen,
6. Replace air inlet grill
smoke and pet dander to form larger particles that are
back onto unit securely.
then more readily captured by the filter system, or may be
attracted to positively charged surfaces throughout the
DO NOT POINT OUTLET TOWARDS WALL.
home, like walls or floors. This may occur more frequently
when the filter is nearing the end of its functional life
expectancy and is able to capture less of the charged
particles.
You may also note after extended use, that dust has
collected around the grills or front panel. This is from the
ionization affect caused by the negative ions exiting from
the air outlet. This is additional evidence of the air
cleaning effectiveness of negative ions. The dust can be
easily removed with a clean, damp cloth or soft brush.
Sunbeam Products, Inc. doing business as Jarden
Consumer Solutions or if in Canada, Sunbeam
Corporation (Canada) Limited doing business as Jarden
Consumer Solutions (collectively "JCS") warrants that for
a period of two years from the date of purchase, this
product will be free from defects in material and
workmanship. JCS, at its option, will repair or replace this
product or any component of the product found to be
defective during the warranty period. Replacement will be
made with a new or remanufactured product or
component. If the product is no longer available,
replacement may be made with a similar product of equal
or greater value. This is your exclusive warranty. Do NOT
attempt to repair or adjust any electrical or mechanical
functions on this product. Doing so will void this warranty.
BAP414CN08EFM1
OPERATING INSTRUCTIONS
1. Plug into a 120V AC electrical outlet.
2. Select the desired operating speed. Air Purifiers have
three speed settings. You can select from HIGH (
MEDIUM ( ) or LOW ( ) by moving the knob to the
desired setting.
3. To release negative ions into the filtered air, turn the
ionizer knob to ON ( ) and the light will illuminate.
4. For optimum air filtration, it is recommended to
operate the air purifier continuously. Its rugged motor
has been designed to give many years of use.
For continuous use, it is recommended to operate the air
purifier at the MEDIUM ( ) setting. For quieter operation
or use in a bedroom, select the LOW ( ) setting. When
high levels of air pollution are present, select the HIGH (
setting to quickly circulate and filter the room air.
Figure 2
B
C
A
D
G
E
F
Figure 1 A. Speed Control Knob E. Washable Foam
Pre-Filter
B. Ionizer Control Knob
F. HEPA-Type Filter
C. Ionizer Indicator Light
G. Filtered Air Outlet
D. Air Inlet Grill
Printed in China
CLEANING INSTRUCTIONS
Turn off and unplug the unit before cleaning.
1. The outside of the air purifier can be cleaned with a
),
soft, damp cloth.
2. The air inlet grill can be removed and washed in warm
soapy water (not dishwasher safe). Dry before
replacing in the unit.
3. The air outlet grill can be cleaned of dust with a small,
soft brush.
WARNING: Do not allow moisture to come in contact
with the main housing of the air purifier.
FILTER REPLACEMENT INSTRUCTIONS
1. Every few weeks, check the condition of the filter.
)
2. Remove the air inlet grill. Remove and examine the
foam pre-filter. If it has collected a noticeable amount
of dust or lint, remove it from the inlet of the grill and
wash it in warm soapy water. Rinse and drip dry the
pre-filter thoroughly before replacing it into the inlet of
the grill.
3. Check the condition of the HEPA-Type filter. If the filter
is dirty, remove the used HEPA-Type cartridge and
properly dispose of it. Do NOT try to wash and re-use
the HEPA-Type filter. Replace with a new HEPA-Type
filter, removing the protective polybag before inserting
into the air purifier.
NOTE: The side with the soft gasket should face
inward.
4. Filter Life – Under normal conditions of continuous
use, the HEPA-Type filter will operate efficiently for 3-6
months.
Replacement filters are available from your local retailer or
by calling 1-800-253-2764.
Air Purifier Filter Quantity Filter # Filter Description
Model # Needed
BAP414-CN 1 BAPF30 HEPA-Type/Carbon
