Bionaire BAP422RC-CN Instruction Leaflet

BAP422RC-CN_08EFM1.qxd:BAP1242/1412/1422CN04EFM2.qxd 5/26/08 9:51 AM
AIR CLEANER SAFETY
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
Air Purifier
INSTRUCTIONS
BAP422RC-CN
MODEL :
When using electrical appliances, basic safety
precautions should always be followed to reduce the risk
of fire, electric shock, and injury to persons, including the
following:
1. Read all instructions before using appliance.
2. To avoid fire and shock hazard, plug the appliance
directly into a 120V AC electrical outlet.
3. If the filter is covered by a bag when shipped: remove
plastic bag before use.
4. Keep the cord out of heavy traffic areas. To avoid fire
hazard NEVER put the cord under rugs, near heat
registers, radiators, stoves or heaters.
5. To protect against electrical hazards DO NOT immerse
in water or other liquids. Do not use near water.
6. Close supervision is necessary when any appliance is
used by, or near children or by disabled persons.
7. Always unplug the air purifeir before moving it,
opening the grill, changing the filters or whenever the
air purifier is not in use. Unplug by pulling on the plug
and not the cord.
8. NEVER drop or insert any object into any openings.
9. Do not operate any appliance with a damaged cord or
plug, if motor fan fails to rotate, after the appliance
malfunctions, or if it has been dropped or damaged in
any manner. Return appliance to manufacturer for
examination, electrical or mechanical adjustment or
repair.
10.Use appliance only for the intended household use as
described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock or injury to persons. The use of
attachments not recommended or sold by The
manufacturer may cause hazards.
11.Do not use outdoors.
Read instructions before operating.
Retain for future reference. 12.Never block the air openings, or place on soft surface,
such as bed or sofa, as this could cause the unit to
Instruction Leaflet
tip over thus blocking the air intake opening.
☎ 13.Keep unit away from heated surfaces and open
INFO-LINE flames.
If after having read this leaflet, you have any
14.DO NOT attempt to repair or adjust any electrical or
questions or comments on your air cleaner, mechanical functions on this unit. Doing so will void
call 1-800-253-2764 in North America.
the warranty. The inside of the unit contains no user
127413/9100040003413
serviceable parts. All servicing should be performed
by qualified personnel only.
CLEANING INSTRUCTIONS
TROUBLESHOOTING
Turn off and unplug the unit before cleaning.
Problem
1. The outside of the air purifier can be cleaned with a
Unit will not operate
soft, damp cloth.
2. The air inlet grill can be removed and washed in warm
soapy water (not dishwasher safe). Dry before
replacing in the unit.
3. The air outlet grill can be cleaned of dust with a small,
soft brush.
Decreased air flow
WARNING: Do not allow moisture to come in contact
with the main housing of the air purifier.
FILTER REPLACEMENT INSTRUCTIONS
1. Every few weeks, check the condition of the filter.
2. Remove the air inlet grill. Remove and examine the
foam pre-filter. If it has collected a noticeable amount
of dust or lint, remove it from the inlet of the grill and
wash it in warm soapy water. Rinse and drip dry the
Excessive Noise
pre-filter thoroughly before replacing it into the inlet of
the grill.
3. Your air purifier is equipped with a filter indicator light
which will alert you when it is time to change the filter.
Under normal conditions of continuous use, the
HEPA-type filter will operate efficiently for 3-6 months.
4. When the filter indicator light goes on, check the
condition of the HEPA-Type filter. If the filter is dirty,
remove the used HEPA-Type cartridge and properly
dispose of it. Do NOT try to wash and re-use the
HEPA-Type filter. Replace with a new HEPA-Type filter,
removing the protective polybag before inserting into
the air purifier.
NOTE: The side with the soft gasket should face
inward.
5. The filter indicator light should be reset once the
HEPA-type filters have been replaced. Reset the
indicator by pressing the Power button ( ) on the
control panel for 2 seconds.
Replacement filters are available from your local retailer or
by calling 1-800-253-2764.
Air Purifier Filter Quantity Filter # Filter Description
Model # Needed
BAP422RC-CN 2
BAPF30 HEPA-Type/Carbon
Page 1
15.WARNING: To reduce the risk of fire or electrical
shock, DO NOT use this air purifier with any solid-
state speed control device.
16.DO NOT place anything on top of the unit.
PLEASE SAVE THESE
INSTRUCTIONS
CONSUMER SAFETY INFORMATION
THIS APPLIANCE HAS A POLARIZED
PLUG (one blade is wider than the other).
To reduce the risk of electric shock, this
plug is intended to fit in a polarized outlet
only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician
to install the proper outlet.
DO NOT DEFEAT THE SAFETY PURPOSE OF THIS
POLARIZED PLUG IN ANY WAY.
The length of the cord used on this product was selected
to reduce the hazards of becoming tangled in, or tripping
over a longer cord. If a longer cord is necessary an
approved extension cord may be used. The electrical
rating of the extension cord must be equal to or greater
than the rating of the air cleaner (refer to the rating label
placed on the air purifier). Care must be taken to arrange
the extension cord where it cannot be pulled on by
children or accidentally tripped over.
IONIZER
Your Air Purifier has an independently controlled ionizer,
which, when turned on, releases negative ions into
outgoing filtered air. Ions are tiny particles that carry a
positive or negative charge. These ions exist naturally
around us, in the air, water and ground. Both positive and
negative ions are colorless, odorless and completely
harmless. Negative ions help the air purification process
by attaching themselves to very small airborne particles in
the room.
These particles take on a negative charge and may join
with positively charged particles such as dust, pollen,
smoke and pet dander to form larger particles that are
then more readily captured by the filter system, or may be
attracted to positively charged surfaces throughout the
home, like walls or floors. This may occur more frequently
when the filter is nearing the end of its functional life
expectancy and is able to capture less of the charged
particles.
You may also note after extended use, that dust has
collected around the grills or front panel. This is from the
ionization affect caused by the negative ions exiting from
the air outlet. This is additional evidence of the air
cleaning effectiveness of negative ions. The dust can be
Solution
Check to make sure unit is
properly plugged in.
Check to make sure the unit is
on by sliding or rotating the
power switch to the ON
position.
Check the filter to see if it is in
good condition and if it needs
to be changed.
Check to ensure nothing is
blocking air inlet and filtered air
outlet.
Make sure that the air intake
grill is at least 1 to 3 feet away
from the wall.
Check to ensure plastic bag(s)
are removed from filter(s).
Check to ensure that parts are
firmly positioned in place.
easily removed with a clean, damp cloth or soft brush. DO NOT POINT OUTLET TOWARDS WALL.
Finally, using your ionizer may result in an occasional OPERATING INSTRUCTIONS
popping or cracking sound. This is a normal sound,
1. Plug into a 120V AC electrical outlet.
generally caused by a small build-up of ions that, when
2. Press the power button (
discharged, cause the popping or cracking sound.
high and the power light will illuminate letting you know
NOTE: It is important to replace the HEPA-Type filter at
the power is on.
the recommended intervals.
3. You can then select the desired speed setting. This air
Using the ionizer in conjunction with dirty filters may result
cleaner has three speed settings. You can select from
in dirty particles exiting the air purifier and being attracted
HIGH (
to walls, carpets, furniture or other household objects.
the desired operating speed button on the control
These dirty particles may prove very difficult to remove.
panel or the remote control.
Homes with excessive amounts of pet dander, dust, or
4. To release negative ions into the filtered air, turn the
smoke may decrease the life expectancy of the
ionizer knob to ON (
HEPA-Type filtration system and may interfere with the
ionization process. You may want to run the Ionizer less 5. For optimum air filtration, it is recommended to
often and check the condition of the HEPA-Type filter(s)
operate the air cleaner continuously. Its rugged motor
more frequently in order to reduce particles from being has been designed to give many years of use. For
attracted to surfaces throughout your home as continuous use, it's recommended to operate the air
mentioned above. cleaner at the MEDIUM (
operation or use in a bedroom, select the LOW (
PRE-OPERATING INSTRUCTIONS
setting. When high levels of air pollution are present,
1. Carefully unpack your Air Purifier. Select a firm, level
select the HIGH (
place where there are no obstructions to the air inlet
filter the room air.
or filtered air outlet. A good location in a room is
approximately 1 foot away from the wall, in a central
location of your home.
Figure 2
2. Pull air inlet grill towards you by grasping the finger
F
tabs on both sides.
3. Remove the HEPA-Type filter by gripping on both
sides and pulling forward.
4. Remove protective plastic bag from the filter cartridge.
5. This model utilizes hang tabs and a filter clip. The clip
can only be attached to the tabs on the filter in only
one way. The filter clip should easily slide onto the
filter hang tab with only a small amount of pressure.
DO NOT use force while attaching the clip to the filter.
Align the clip on the top of the HEPA-Type filter with
the rails on the inside of
the purifier unit. Gently
Figure 1 D
slide the filter onto the
rail (Figure 1).
NOTE: The side with
A. INLET GRILL
the soft gasket should
face inward. B. WASHABLE FOAM
PRE-FILTER
6. Replace air inlet grill back onto unit securely.
C. SPEED CONTROL
D. POWER INDICATOR
E. FILTERED AIR OUTLET
Sunbeam Products, Inc. doing business as Jarden
Consumer Solutions or if in Canada, Sunbeam
Corporation (Canada) Limited doing business as Jarden
Consumer Solutions (collectively "JCS") warrants that for
a period of two years from the date of purchase, this
product will be free from defects in material and
workmanship. JCS, at its option, will repair or replace this
product or any component of the product found to be
defective during the warranty period. Replacement will be
made with a new or remanufactured product or
component. If the product is no longer available,
replacement may be made with a similar product of equal
or greater value. This is your exclusive warranty. Do NOT
attempt to repair or adjust any electrical or mechanical
functions on this product. Doing so will void this warranty.
BAP422RCCN08EFM1
REMOTE CONTROL
Your remote control requires (2) AAA batteries (not
included) for operation.
To install the batteries, simply depress and slide the back
). The unit will turn onto
of the remote control with your thumb on the arrow
indentation. Insert batteries according to the diagram
shown inside and replace cover.
• Do NOT mix old and new batteries.
), MEDIUM ( ), or LOW ( ) by pushing • DO NOT mix alkaline, standard (carbon-zinc) or
rechargeable (nickel-cadmium) batteries.
1. Set tower air cleaner on a dry, level surface.
2. Plug cord into any standard 120V AC outlet.
) and the light will illuminate.
3. To turn the air cleaner on, press the power button (
and then select the desired operating speed by
pressing any speed button on the remote control or
on the control panel.
4. The speed is adjustable by pressing either the Speed
) setting. For quieter
Buttons: HIGH ( ), MEDIUM (
)
the remote control or on the control panel.
) setting to quickly circulate and
5. To turn the unit off, press the power button (
either the remote control or on the control panel.
6. To turn the Ionizer on, press the ionizer button (
on either the remote control or the control panel.
H
Figure 3
G
A
B
E
I
C
Speed
Controls
REMOTE CONTROL
F. FILTER INDICATOR
LIGHT
G. IONIZER CONTROL
H. IONIZER LIGHT
I. HEPA-TYPE/CARBON
FILTER
Printed in China
)
), or LOW ( ) on
) on
)
Power Button
Ionizer
Control
