| Making Network Connections
C 4
HAPTER

Cable Labeling and Connection Records

10 M E
BPS THERNET

Table 10: Maximum Ethernet Cable Length

Type Cable Type
10BASE-T Category 3 or better 100-ohm UTP
C L
ABLE ABELING AND
When planning a network installation, it is essential to label the opposing ends of
cables and to record where each cable is connected. Doing so will enable you to
easily locate inter-connected devices, isolate faults and change your topology
without need for unnecessary time consumption.
To best manage the physical implementations of your network, follow these
guidelines:
Clearly label the opposing ends of each cable.
◆
Using your building's floor plans, draw a map of the location of all network-
◆
connected equipment. For each piece of equipment, identify the devices to
which it is connected.
Note the length of each cable and the maximum cable length supported by
◆
the switch ports.
For ease of understanding, use a location-based key when assigning
◆
prefixes to your cable labeling.
Use sequential numbers for cables that originate from the same equipment.
◆
Differentiate between racks by naming accordingly.
◆
Label each separate piece of equipment.
◆
Display a copy of your equipment map, including keys to all abbreviations at
◆
each equipment rack.
C D
OLLISION OMAIN
C
ONNECTION
– 51 –
Max. Cable Length
100 m (328 ft)
R
ECORDS
Connector
RJ-45
