SMC Networks SMCGS501P User Manual

Ez switch 10/100/1000 5-port gigabit ethernet poe switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER GUIDE

TM
EZ Switch
10/100/1000
5-Port Gigabit Ethernet PoE Switch
SMCGS501P

Advertisement

Table of Contents
loading

Related Manuals for SMC Networks SMCGS501P

Summary of Contents for SMC Networks SMCGS501P

  • Page 1: User Guide

    USER GUIDE EZ Switch 10/100/1000 5-Port Gigabit Ethernet PoE Switch SMCGS501P...
  • Page 2 EZ Switch 10/100/1000 User Guide From SMC’s EZ line of low-cost workgroup LAN solutions No. 1, Creation Road III, Hsinchu Science Park, 30077, Taiwan, R.O.C. September 2014 TEL: +886 3 5638888 E092014-AP-R01 Fax: +886 3 6686111...
  • Page 3 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.

  • Page 4: Warranty And Product Registration

    ARRANTY AND RODUCT EGISTRATION To register SMC products and to review the detailed warranty statement, please refer to the Support Section of the SMC Website at http://www.smc.com. – 4 –...

  • Page 5: Compliances And Safety Statements

    OMPLIANCES AND AFETY TATEMENTS EDERAL OMMUNICATION OMMISSION NTERFERENCE TATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 6 OMPLIANCES AND AFETY TATEMENTS CE M (EEC) ECLARATION OF ONFORMANCE FOR AFETY Declaration of Conformity (DoC) can be obtained from www.smc.com -> support -> download This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/ 68/EEC.
  • Page 7 OMPLIANCES AND AFETY TATEMENTS LASS This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications. Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques,”...
  • Page 8 OMPLIANCES AND AFETY TATEMENTS Pay attention to the power load of the outlet or prolonged lines. An ◆ overburdened power outlet or damaged cords and plugs may cause electric shock or fire. Check the power cords regularly, if you find any damage, replace it at once.
  • Page 9 OMPLIANCES AND AFETY TATEMENTS Ne placez pas cet appareil à proximité d’un lieu humide ou mouillé. Prenez ◆ garde à ne renverser aucun liquide sur cet appareil. Merci de suivre les instructions du manuel d'utilisateur / guide d’installation ◆ rapide attentivement pour connecter l'appareil à votre PC ou à tout autre produit électronique.
  • Page 10 OMPLIANCES AND AFETY TATEMENTS RECAUCIONES DE SEGURIDAD Lea la siguiente información detenidamente antes de utilizar el dispositivo. Siga las indicaciones de precaución que se mencionan a continuación para proteger el dispositivo contra riesgos y daños causados por el fuego y la energía eléctrica: Utilice el adaptador de alimentación incluido en el paquete del dispositivo.
  • Page 11 OMPLIANCES AND AFETY TATEMENTS Respeite a potência da tomada eléctrica e das extensões. Uma tomada ◆ eléctrica sobrecarregada ou cabos e fichas danificadas podem causar choques eléctricos ou fogo. Verifique regularmente os cabos de alimentação. Caso algum se encontre danificado, substitua-o imediatamente.

  • Page 12: About This Guide

    BOUT UIDE URPOSE This guide details the hardware features of the switch, including the physical and performance-related characteristics, and how to install the switch. UDIENCE The guide is intended for use by network administrators who are responsible for installing and setting up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area Networks).

  • Page 13: Table Of Contents

    ONTENTS ARRANTY AND RODUCT EGISTRATION OMPLIANCES AND AFETY TATEMENTS BOUT UIDE ONTENTS NTRODUCTION Overview Features PoE Features ARDWARE ESCRIPTION Front Panel Port and System Status LEDs Rear Panel RJ-45 Ports Power Connector NSTALLING THE WITCH Package Contents Precautions Safety Requirements Location Requirements Powering On Connecting Network Devices...
  • Page 14 ONTENTS Department/Workgroup PoE Switch Power over Ethernet Powered Devices ROUBLESHOOTING Diagnosing Switch Indicators The Power LED is Off The Link/Act LED is Off when a Device is Connected to the Corre- sponding Port Power and Cooling Problems Installation PECIFICATIONS Physical Characteristics –...

  • Page 15: Introduction

    NTRODUCTION VERVIEW The EZ Switch 10/100/1000 SMCGS501P PoE switch provides five 10/100/1000 Mbps auto-negotiating RJ-45 ports. Each port on the switch support auto MDI/ MDI-X, which eliminates the need for crossover cables or uplink ports. The switch is plug-and-play; any port can be connected to a server, a hub, or a switch, using straight-through or crossover cable.

  • Page 16: Poe Features

    Overview EATURES The SMCGS501P can provide up to 30 Watts of power to one attached device, such as a VoIP phone, wireless access point, or surveillance camera, etc, over existing Cat. 5 cable. The switch can deliver up to 15.4/30 Watts on Port 1,...

  • Page 17: Hardware Description

    ESCRIPTION This chapter describes the front panel, rear panel, and LED indicators of the switch. RONT ANEL The front panel of SMCGS501P consists of switch LED indicators. Figure 1: SMCGS501P Switch Front Panel ORT AND YSTEM TATUS This switch includes a display panel for key system and port indications that simplify installation and network troubleshooting.

  • Page 18: Rear Panel

    On Green A PoE device is connected. No PoE device connected. ANEL Figure 2: SMCGS501P Switch Rear Panel RJ-45 P ORTS The switch contains five 1000BASE-TX RJ-45 ports. All ports support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs.

  • Page 19: Installing The Switch

    SMC distributor. Also be sure you have all the necessary tools and cabling before installing the switch. ACKAGE ONTENTS The following contents should be found in your package: One SMCGS501P Switch ◆ One AC-DC power adapter ◆ One power cord ◆...

  • Page 20: Location Requirements

    OWERING The SMCGS501P switch is powered by connecting to an AC power supply using the included AC-DC power adapter. When powering on the switch, it automatically initializes and the LED indicators respond as follows: All of the LED indicators flash momentarily for one second, which represents a resetting of the system.

  • Page 21: Connecting Network Devices

    | Installing the Switch HAPTER Connecting Network Devices ONNECTING ETWORK EVICES This switch is designed to be connected to 10, 100 or 1000 Mbps network cards in PCs and servers, as well as to other switches and hubs. ABLING UIDELINES The RJ-45 ports on the switch support automatic MDI/MDI-X pinout configuration, so you can use standard straight-through twisted-pair cables to connect to any other network device (PCs, servers, switches, routers, or hubs).

  • Page 22: Department/Workgroup Poe Switch

    EPARTMENT ORKGROUP WITCH The SMCGS501P is specially designed as part of a Multi-Service Operator (MSO) solution for an IPTV system. The Edge-Core ECS4510-12PD is a PoE PD (powered device) switch that can operate in a cost-effective combination with the SMCGS501P.

  • Page 23: Product Application

    | Product Application HAPTER Power over Ethernet Powered Devices OWER OVER THERNET OWERED EVICES Table 2: Power over Ethernet Powered Devices Voice over IP phones Enterprises can install PoE VoIP phones, ATA and other Ethernet/ non-Ethernet end-devices connected to a central location where an un-interruptible power supply and power control system are installed.

  • Page 24: A Troubleshooting

    ROUBLESHOOTING IAGNOSING WITCH NDICATORS OWER Make sure the AC-DC power adapter is connected to the switch and power ◆ source properly. Make sure the power source is ON. ◆ FF WHEN A EVICE IS ONNECTED TO THE ORRESPONDING Make sure that the cable connectors are firmly plugged into the switch and ◆...

  • Page 25: Installation

    | Troubleshooting PPENDIX Installation NSTALLATION Verify that all system components have been properly installed. If one or more components appear to be malfunctioning (such as the power cord or network cabling), test them in an alternate environment where you are sure that all the other components are functioning properly.

  • Page 26: B Specifications

    PECIFICATIONS HYSICAL HARACTERISTICS TANDARDS IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE802.3ab 1000BASE-T IEEE 802.3X Flow Control EATURES IEEE 802.3x Flow Control Auto MDI/MDI-X Supports auto-negotiation of speed (10/100/1000 Mbps) and duplex mode (half/ full) Wire-speed packet filtering and forwarding rate Store-and-forward architecture filters fragment &...
  • Page 27 | Specifications PPENDIX Physical Characteristics WITCHING ATABASE 2K MAC address entries UFFER EMORY 2K Bits per device WITCHING APACITY 10 Gbps HROUGHOUT 7.4 Mpps IMENSIONS 14.0 x 7.7 x 2.7 cm (5.51 x 3.03 x 1.06 in.) EIGHT 256 g (0.56 lbs) OWER UPPLY AC Input: 100~240 V, 50/60 Hz...
  • Page 28 | Specifications PPENDIX Physical Characteristics MMUNITY EN55024 IEC61000-4-2/3/4/5/6/8/11 MISSIONS FCC Class A, EN55022/EN61000-3-2/3 EMPERATURE Operating: 0 to 50 °C (32 to 122 °F) Storage: -40 to 70 °C (-40 to 158 °F) UMIDITY Operating: 10% to 90% (non-condensing) Storage: 5% to 90% (non-condensing) –...
  • Page 30 Tel: +886 3 563 8888 Fax: +886 3 668 6111 su www.smc.com www.smc-asis.com www.smcnetworks.co.kr Declaration of Conformity (DoC) can be obtained from www.smc.com -> support -> download SMCGS501P www.smc.com 150200062800A R02 20 Mason • Irvine, CA 92618 • Phn: 949-679-8000 • www.smc.com...
