USER GUIDE EZ Switch 10/100/1000 5/8-Port Gigabit Ethernet Switches SMCGS501/SMCGS801... - Page 2 EZ Switch 10/100/1000 User Guide From SMC’s EZ line of low-cost workgroup LAN solutions 20 Mason May 2011 Irvine, CA 92618 SMC-UG-0511-01 Phone: (949) 679-8000...
- Page 3 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.
-
Page 4: Warranty And Product Registration
ARRANTY AND RODUCT EGISTRATION To register SMC products and to review the detailed warranty statement, please refer to the Support Section of the SMC Website at http://www.smc.com. – –... - Page 5 CE M (EEC) ECLARATION OF ONFORMANCE FOR AFETY SMC contact for these products in Europe is: SMC Networks Europe, C/Fructuós Gelabert 6-8, 2o, 2a, Edificio Conata II, 08970 - Sant Joan Despí, Barcelona, Spain. – 5 –...
-
Page 6: Compliances And Safety Statements
OMPLIANCES AND AFETY TATEMENTS This information technology equipment complies with the requirements of the Council Directive 2004/108/EC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 2006/95/EC for electrical equipment used within certain voltage limits and the Amendment Directive 2006/95/EC. - Page 7 OMPLIANCES AND AFETY TATEMENTS LVD: EN 60950-1:2006 ◆ CE M ARNING This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022 class A for ITE, the essential protection requirement of Council Directive 2004/108/EC on the approximation of the laws of the Member States relating to electromagnetic compatibility.
- Page 8 OMPLIANCES AND AFETY TATEMENTS – 8 –...
-
Page 9: About This Guide
BOUT UIDE URPOSE This guide details the hardware features of the switch, including the physical and performance-related characteristics, and how to install the switch. UDIENCE The guide is intended for use by network administrators who are responsible for installing and setting up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area Networks). - Page 10 BOUT UIDE – 10 –...
-
Page 11: Table Of Contents
ONTENTS ARRANTY AND RODUCT EGISTRATION OMPLIANCES AND AFETY TATEMENTS BOUT UIDE ONTENTS NTRODUCTION Overview Package Contents Features IEEE 802.1p QoS ARDWARE ESCRIPTION Port and System Status LEDs Installation PC Connections Switch Connections ROUBLESHOOTING Diagnosing Switch Indicators The POWER LED is Off The LINK/ACT LED is Off when a Device is Connected to the Cor- responding Port Power and Cooling Problems... - Page 12 ONTENTS – 12 –...
-
Page 13: Contents
NTRODUCTION VERVIEW The EZ Switch 10/100/1000, SMCGS501 and SMCGS801, are powerful, high- performance Gigabit Ethernet switches with 5 or 8 ports. The switches support auto-negotiation on all ports, which means they automatically negotiate with connected partners to determine the network speed (10/100/1000 Mbps) and duplex mode (full or half duplex). -
Page 14: Features
| Introduction HAPTER Package Contents SMC Warranty Card ◆ Quick Install Guide ◆ EATURES Complies with 10BASE-T specifications of the IEEE 802.3 standard ◆ Complies with 100BASE-TX specifications of the IEEE 802.3u standard ◆ Complies with 1000BASE-T specifications of the IEEE 802.3ab standard ◆... -
Page 15: Ieee 802.1P Qos
HAPTER Package Contents IEEE 802.1 The SMCGS501 and SMCGS801 switches support 802.1p priority queuing Quality of Service, which is an implementation of the IEEE 802.1p standard. With the 802.1p QoS function, you can reserve bandwidth for important functions that require a lot of bandwidth or have a high priority, such as VoIP (Voice-over Internet Protocol), web browsing applications, or video conferencing. - Page 16 | Introduction HAPTER Package Contents – 16 –...
- Page 17 The switch contains one power LED for the device and LINK/ACT LEDs for each port. Please refer to the following table for LEDs definition: Figure 2: Front Panels 5-Port EZ Switch 10/100/1000 Mbps SMCGS501 802.az 8-Port EZ Switch 10/100/1000 Mbps SMCGS801 802.az...
-
Page 18: Hardware Description
| Hardware Description HAPTER Installation NSTALLATION When installing the switch, follow these guidelines: Place the switch with appropriate ventilation environment. A minimum of 25 ◆ mm space around the unit is recommended. Place the switch and connected cables away from sources of electrical noise, ◆... -
Page 19: Power And Cooling Problems
ROUBLESHOOTING IAGNOSING WITCH NDICATORS POWER LED Make sure the AC power cord is connected to the switch and power source ◆ properly. Make sure the power source is ON. ◆ LINK/ACT LED FF WHEN A EVICE IS ONNECTED TO THE ORRESPONDING Make sure that the cable connectors are firmly plugged into the switch and ◆... -
Page 20: Installation
| Troubleshooting PPENDIX Installation NSTALLATION Verify that all system components have been properly installed. If one or more components appear to be malfunctioning (such as the power cord or network cabling), test them in an alternate environment where you are sure that all the other components are functioning properly. -
Page 21: Specifications
IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX IEEE802.3ab 1000BASE-T IEEE802.3x full duplex flow control IEEE 802.3az IEEE 802.1p QoS NTERFACE SMCGS501: 5 10/100/1000BASE-T RJ-45 ports SMCGS801: 8 10/100/1000BASE-T RJ-45 ports ETWORK 10/100/1000 Mbps Auto-negotiating RANSMISSION 10/100 Mbps: Full-duplex, Half-duplex 1000 Mbps: Full-duplex WITCHING... - Page 22 System: Power Ports: Link/Act OWER UPPLY External power adapter 5V/1A IMENSIONS SMCGS501: 121.0 x 75.0 x 26.0 mm (4.84 x 3.0 x 1.0 in.) SMCGS801: 154.5 x 85.0 x 26.0 mm (6.18 x 3.4 x 1.0 in.) – 22 –...
- Page 23 | Specifications PPENDIX Physical Characteristics EIGHT SMCGS501: 253 g (0.12 lbs) SMCGS801: 355 g (0.16 lbs) MISSIONS FCC, CE – 23 –...
