1
I
NTRODUCTION
O
VERVIEW
The SMCGS10P-Smart is a Gigabit Ethernet Layer 2 PoE switch with 8 10/100/
1000BASE-T ports, and 2 Small Form Factor Pluggable (SFP) transceiver slots,
(see "Front Panel" on page 22, Ports 9-10). The SMCGS10P-Smart also provides
PoE power to connected devices.
The switch also includes an SNMP-based management agent, which provides in-
band access for managing the switch.
Both switches provide a broad range of powerful features for Layer 2 switching,
delivering reliability and consistent performance for your network traffic. It
brings order to poorly performing networks by segregating them into separate
broadcast domains with IEEE 802.1Q compliant VLANs, and empowers
multimedia applications with multicast switching and CoS services.

Figure 1: Front Panel

Port Status Indicators
SFP Port Status Indicators
SMCGS10P-Smart
/
Reset Button 10/100/1000 Mbps RJ-45 PoE Ports
1000BASE-T/SFP Ports
System Indicators
