MS-7003 M-ATX Mainboard

Speaker Test

You can use this tab to test each connected speaker to ensure if 4- or 6-
channel audio operation works properly. If any speaker fails to make sound,
then check whether the cable is inserted firmly to the connector or replace the
bad speakers with good ones.
Front Left
Rear Left
Select the speaker by clicking it to test its functionality. The one you
select will light up and make testing sound.
A-8
Center
Front Right
Subwoofer
Rear Right
