These instructions tell you how to install the Internal Rewinder in an

EasyCoder PD41/PD42 printer. Use the internal rewinder to operate the

printer in peel-off mode or batch takeup mode. The kit includes the

following:

Rewinder module with liner

retention clip

Required Tools

To install the interface board in your printer, you need:

• Screwdriver, Phillips

Installing the Internal Rewinder

Before you begin installation, please acknowledge the following important

safety note:

Take precautions against electrostatic discharge, for

example, by wearing grounded wrist straps.

EasyCoder

Internal Rewinder Installation Instructions

Liner retention guide

PD41/PD42

Four screws (M3x4.5)

Page 1 PD41/PD42 Internal Rewinder Installation Instructions These instructions tell you how to install the Internal Rewinder in an EasyCoder PD41/PD42 printer. Use the internal rewinder to operate the printer in peel-off mode or batch takeup mode. The kit includes the following: Four screws (M3x4.5)
Page 2 To install the internal rewinder 1 Open the side door of the printer. 2 Remove the two screws that hold the rewinder option cover plate in place. Keep the screws. Cover plate 3 Remove the liner retention clip from the rewinder unit. 4 Attach the rewinder unit to the printer using two of the screws included in the kit with the two screws that were previously used to hold the cover plate in place.
Page 3 Using the Internal Rewinder for Batch Takeup Operation In batch takeup operation, labels are wound up on the internal rewinder instead of being peeled off at the tear bar. To be able to use the internal rewinder for batch takeup, you need to also install the liner retention guide. To install the liner retention guide 1 Remove the thumbscrew to remove the front cover.
Page 4 Loading Media in the Printer For information on how to load the printer with media for peel-off or batch takeup operation, please refer to the EasyCoder PD41 Printer User’s Guide (P/ N 1-960652-xx) or the EasyCoder PD42 Printer User’s Guide (P/N 934-009- xxx).
