Thermal Printhead (200/300 dpi) Installation Instructions

These instructions tell you how to install a 200 dpi or 300 dpi thermal

printhead in an EasyCoder PD4/PD41/PD42 printer. The kit contains the

following:

• 200 dpi or 300 dpi thermal printhead

• Printhead adapter printed circuit board (PCB)

Required Tools

To install the interface board in your printer, you need these tools:

• Screwdriver, slotted

• Screwdriver, Phillips (with magnetic tip)

Installing the Thermal Printhead and the Adapter PCB

Before you begin installation, please acknowledge the following important

safety notes:

Make sure the printer has been turned off and

disconnected from the power supply before you

start installation.

Stellen Sie sicher, dass der Drucker abgeschaltet

und von der Stromversorgung abgetrennt wurde,

bevor Sie mit der Installation beginnen.

Take precautions against electrostatic discharge, for

example, by wearing grounded wrist straps.

EasyCoder

PD4/PD41/PD42

Page 1 Thermal Printhead (200/300 dpi) Installation Instructions These instructions tell you how to install a 200 dpi or 300 dpi thermal printhead in an EasyCoder PD4/PD41/PD42 printer. The kit contains the following: • 200 dpi or 300 dpi thermal printhead • Printhead adapter printed circuit board (PCB)
Page 2 200 dpi to 300 dpi). If this is not the case, go to Step 11. Note: If you are using a PD4 printer, you cannot switch to a printhead with a different resolution other than that which the...
Page 3 7 Use an appropriate tool, for example a slotted screwdriver, to carefully pry the printhead cable connector loose from the adapter PCB. 8 Remove the two screws that attach the adapter PCB to the printer. Remove the adapter PCB. 9 Attach the new adapter PCB with the two screws removed in Step 8.
Page 4 14 Plug in the power cord and turn the printer on. Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2007 Intermec Technologies Corporation. All rights reserved. EasyCoder PD4/PD41/PD42 Thermal Printhead (200/300dpi) Installation Instructions *1-960658-02* P/N 1-960658-02...
