1.4.1 Label Loading Instructions

To load labels complete the following steps:
1. Disengage the Printhead by rotating the Head-Lift Lever
2. Slide the Media Guide to the outer edge of the guide and
3. Slide the Retainer to the outer edge of the Supply
4. Place the label roll on the Supply Mount and slide the
5. Insert the label stock as shown in Figure 1-6.
6. Route the Media Guide 'up' and slide it to the edge of
7. Engage the Printhead by rotating the Head-Lift Lever
If the Media is not sensing, try adjusting the sensor position by
turning the adjustment knob for the movable sensor. The gauge
behind and below the Printhead can be viewed for making this
adjustment. If the label's edge is not detected within 12" (305mm) of
feeding, the Printer will stop and the 'Paper Out' Indicator will
remain illuminated. In this case, check the threading of the Media
around the bottom of the upper and lower Media Guides.
If the paper feeds forward only about 2.5" (64mm) each time you
press the Feed Button, and does not seem to be stopping on a label
edge, the Ribbon on/off Switch, (shown in Figure 1-5) was
probably turned on without Thermal-Transfer Ribbon being
installed. Slide this switch toward the front of the Printer for Direct-
Thermal Printing.
Allegro2
Getting Started
counterclockwise to the 'up' position.
rotate it to the 'down' position.
Mount.
Retainer firmly against it.
the Media.
clockwise to the 'down' position.
