Appendix F
Specifications
Printing
Type:
Resolution:
Print Speed:
Barcode Modules:
Maximum Print Width:
Maximum Print Length:
White Space Slew Rate:
Maximum Fields Per
Label:
Minimum Dot Size:
Optional Dot Sizes:
Label Backfeed:
Allegro2
Direct thermal or thermal transfer
203 dots per inch (8 dots/mm)
2.0 3.0" (51 mm 76 mm) per second
5 mil to 110 mil (.0005
dimension in picket or ladder orientation
4.1" (104mm)
8.25" (210mm) with standard RAM; up to
20.25" (514mm) with optional 512K memory
module
2.0" 3.0" (51mm 76 mm) per second
200; 5K data per label maximum
0.005" (0.125mm) square
0.010" (0.250mm) vertical; 0.015" (0.381mm)
vertical; 0.010" (0.250mm) horizontal
For use with optional Cutter or Peel and Present.
" - .110")
"X"
F-1
