Communications Interfacing - Datamax Allegro 2 Operator's Manual

Lists of Approved Media
For a current list approved standard Media for use in Thermal and
Thermal-Transfer Printers, please contact your customer support
representative.
Lights, Buttons, Switch and POT
Lights:
Buttons:
Switches:
POT:

Communications Interfacing

IEEE RS-232C +RS-422 at 300, 600, 1200, 2400, 4800, or 9600 baud
Character Set: ANSI ASCII character set
Word Length:
Handshaking:
Input Buffer:
Electrical
Power Source:
Circuit Protection:
Grounding:
Allegro2
Specifications
Power, Paper/Ribbon and Pause
Pause, Feed and Stop/Cancel
Ribbon
Darkness
Selectable 7-bit or 8-bit data format
Xon/Xoff (in receive mode only) and CTS/DTR
Approximately 7000 bytes. Xoff is transmitted and DTR
goes low when 750 bytes are available in the buffer.
Xon is transmitted and DTR goes high when 750 bytes
are left in the buffer. Characters are transmitted with no
parity from the Printer.
115, 220/240 VAC, 50/60 Hz
115 VAC: 1 amp time delay fuse; 230: 2 time delay
fuses T 0.5 amp
Unit must be connected to a properly-grounded
receptacle
F-5
