Specifications

Physical
Case Material
Dimensions (L x H x W)
Cable Length
Mini DIN Connector
Optical
Scan Rate
Wavelength of LED Illumination
Read Sensor
Narrow Bar Resolution
Maximum Character Input
Maximum Scanning Width
Minimum Print Contrast Signal
Symbology Orientation
Electrical
Operating Voltage
Current:
Operating
Static
Surge
Environmental
Temperature:
Operating
Storage
Humidity (non-condensing):
Operating
Storage
Ambient light restrictions:
Supported Symbologies*
Codabar (NW-7)
Code 128
MSI / Plessey
* Bitmapped images and UPC 2 & 5 digit addendums only readable when specified by number in BARCODE COUNT.
Steel (Black)
47 x 20 x 55 mm (1.95 x 0.78 x 2.2 in)
7.0 inches with 8 pin Mini DIN connection
Pin Number:
1
2
3
4
5
6
7
8
700 scans per second ±10%
660 nanometers
CCD linear array
Mounting position dependent: 10-mil or 5-mil
51 digits
4.0 inches (101 mm) @ the10-Mil position; and,
3.5 inches (89 mm) @ the 5-Mil position.
0.45 (min. background reflectance of 70%)
Picket fence
+5 VDC + 5%
158 mA typical, 220 mA maximum
150 mA maximum
3 A maximum
0 to +40 C (+32 to +104 F)
-10 to +60 C (+14 to +140 F)
20 to 80%
20 to 90%
Fluorescent or incandescent: below 5 kilolux
Code 39
Industrial 2 of 5
WPC (UPC / EAN / JAN)*
22
Signal:
+5 VDC
TXD
Trigger
RTS
Signal Ground
Chassis Ground
RXD
8-pin Mini DIN Connector
CTS
Code 93
Interleaved 2 of 5
IATA
MD-80
