TRENDnet TEG-240WS - DATA SHEETS User Manual

24-port 10/100/1000mbps gigabit web-based smart switch
Hide thumbs Also See for TEG-240WS - DATA SHEETS:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version
FCC Warning
This equipment has been tested and found to comply with the
regulations for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with this user's guide, may cause harmful interference to
radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case the user will
be required to correct the interference at his or her own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product
may cause radio interference, in which case the user may be required
to take adequate measures.
VCCI Warning
This is a product of VCCI Class A Compliance.

Advertisement

Table of Contents
loading

Related Manuals for TRENDnet TEG-240WS - DATA SHEETS

Summary of Contents for TRENDnet TEG-240WS - DATA SHEETS

  • Page 1 FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 2 (Tmra). b) Reduced Air Flow- Installation of the equipment in a rack should be such that the amount of air flow required for safe operation of the equipment is not compromised. c) Mechanical Loading- mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to uneven mechanical loading.

  • Page 3: Table Of Contents

    Configuring Setup Setting.............. 27 Switching Technology ..............5 Port Settings ................27 VLAN (Virtual Local Area Network)..........6 VLAN Settings (Virtual Local Area Network) ......29 Features.................... 6 Trunk Setting ................30 Unpacking and Installation ..............9 Mirror Setting................31 Unpacking ..................

  • Page 4: About This Guide

    This guide discusses how to install your 24-Port 10/100/1000Mbps Gigabit Web Smart Switch. Terms/Usage In this guide, the term “Switch” (first letter upper case) refers to your 24-Port 10/100/1000Mbps Gigabit Ethernet Web Smart Switch, and “switch” (first letter lower case) refers to other Ethernet switches.

  • Page 5: Introduction

    Likewise, since data transfers occur 10 times faster than advantage of the existing investment in hardware, software, and Fast Ethernet, servers outfitted with Gigabit Ethernet NIC’s are able to personnel training. perform 10 times the number of operations in the same amount of time.

  • Page 6: Switching Technology

    VLAN (Virtual Local Area Network) Another approach to pushing beyond the limits of Ethernet technology A VLAN is a group of end-stations that are not constrained by their is the development of switching technology. A switch bridges physical location and can communicate as if a common broadcast Ethernet packets at the MAC address level of the Ethernet protocol domain, a LAN.
  • Page 7 512KBytes packet buffer Supports IEEE 802.3x flow control for full-duplex mode ports Supports Port-base VLAN Supports Port-base QoS Supports Trunk. Supports Port-mirroring Supports Port-setting for Speed/Disable, Flow control Easy configuration via WEB Browser Easy setting via Web Management Utility Standard 19” Rack-mount size...

  • Page 8: Unpacking And Installation

    This chapter provides unpacking and installation information for the sunlight. Switch. Leave at least 10cm of space at the front and rear of the hub for ventilation. Unpacking Install the Switch on a sturdy, level surface that can support its weight, Open the shipping cartons of the Switch and carefully unpacks its or in an EIA standard-size equipment rack.

  • Page 9: Connecting Network Cable

    AC Power The Switch used the AC power supply 100-240V AC, 50-60 Hz. The power switch is located at the rear of the unit adjacent to the AC power connector and the system fan. The switch’s power supply will adjust to the local power source automatically and may be turned on Figure 2.

  • Page 10: Identifying External Components

    “Reset” button. function gives true “plug and play” capability, just need to plug-in the network cable to the hub directly and don’t care if the end node is NIC (Network Interface Card) or switch and hub.

  • Page 11: Understanding Led Indicators

    : When the Power LED lights on, the Switch is receiving power. 100Mbps : When the Power turns off or the power cord has improper connection. When the 100Mbps LED lights on, the respective port is connected to a 100Mbps Fast Ethernet network.

  • Page 12: Configuration

    By pressing the “Discovery” button, you can list all the Web Management devices in the discovery list. Double click or press the “Add to monitor list” button to select a device from the Discovery List to the Monitor List.

  • Page 13: Monitor List

    Note: In order to receive Trap information, switch has to be configured with System Name: Shows the appointed device system name. Trap IP and Trap Events in Web browser, which are available in the Trap Location: Shows where the device is located.

  • Page 14: Device Setting

    Select the device in the Discovery list or Monitor List and press this button, then the Configuration Setting window will pop out as Figure 10, after filling up the data that you want to change, you must fill up Figure 11. Password Change the password and press the “Set”...

  • Page 15: Toolbar

    Choose 15 secs, Switch is 192.168.0.1, then the manager PC should be set at 30 secs, 1 min, 2 min and 5 min to select the time of monitoring. 192.168.0.x (where x is a number between 2 and 254), and the default subnet mask is 255.255.255.0.

  • Page 16: Setup Menu

    Figure 15. Device Status Setup Menu When the main page appears, find the Setup menu in the left side of the screen (Figure 16). Click on the setup item that you want to configure. There are eleven options: Port Settings, VLAN Settings, Figure 14.

  • Page 17: Configuring Setup Setting

    Figure 17. Port Setting Figure 16. Setup menu To change the port setting, click on the ID parameter to enter to the selected port to configure its Speed/Disable, Flow control and QoS Configuring Setup Setting setting.

  • Page 18: Vlan Settings (Virtual Local Area Network)

    This setting determines whether or not the Switch will be handling flow control. Set Flow Control to Enable for avoiding data transfer overflow. Or it sets to Disable; there is either no flow control or other hardware/software management. When the port is set to forced mode, then the flow control will Figure 20.

  • Page 19: Mirror Setting

    Mirror Setting Device Status Click on the “Status” to present the device status on this screen, it will Port Mirroring is a method of monitoring network traffic that forwards show the System Status, Port Status, VLAN Status, Trunk Status and a copy of each incoming and/or outgoing packet from one port of a Mirror Status..

  • Page 20: Statistic

    The Login Timeout is to set the idle time-out for security issue, when there is no action in running the Web Smart Utility and the time is up, you must re-login to Web Smart Utility before you set the Utility.

  • Page 21: Trap Setting

    Be aware that the entire configuration Management Switch, use this function to change the password. will be reset, the IP address of the device will be set to default setting If you forget the password, press the “Reset” button in the rear panel 192.168.0.1.

  • Page 22: Logout

    Logout When press this function, the web configuration will go back to first Login page. Figure 30. Logout...

  • Page 23: Technical Specifications

    Operating: 0° ~ 40° C, Storage: -10° ~ 70° C Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90% Dimensions 440 x 210 x 44 mm (W x H x D) EMI: FCC Class A, CE Mark Class A, VCCI Class A Safety:...
  • Page 24 WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN product or part to replace the defective item, or refund to customer the LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR purchase price paid for the defective product. All products that are IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, replaced will become the property of TRENDware.
  • Page 25 BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), TRENDware provides FREE technical support for all FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, customers for the duration of the warranty period on this OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF product.
