Summary of Contents for TRENDnet TPE-224WS
- Page 1 Quick Installation Guide TPE-224WS...
-
Page 2: Table Of Contents
Table of Contents Table of Contents English ... 1. Before You Start 2. Hardware Installation ... 3. Web Management Utility ... Troubleshooting ... Version 03.13.2006... -
Page 3: English
Power over Ethernet 108Mbps 802.11g (PoE) Splitter Wireless Access Point (TPE-102S) (TEW-450APB) Power + Ethernet Data Package Content TPE-224WS Quick Installation Guide Utility CD-ROM 2 mounting brackets with screws AC Power Cord 108Mbps 802.11g Hot-Spot Access Point (TEW-453APB) 108Mbps 802.11g... -
Page 4: Hardware Installation
2. Hardware Installation 1. Connect the Power Cord to the rear of the TPE-224WS and then to a power outlet. 2. Connect a CAT-5 network cable from the computer to an available Ethernet port of the TPE-224WS. English... -
Page 5: Web Management Utility
3. Web Management Utility Note: If you would like to easily discover all the Web Management Switches on the network, assign IP Address, change the password, and upgrade to new firmware, then install the Web Management Utility. Follow the steps below. For Windows User 1. - Page 6 4. Click Discovery, and then double- click the Switch that appears in the Discovery List. 5. Click the Switch in the Monitor List and then click Configuration setting. 6. Configure the IP Address, Subnet mask, Gateway, and Password. Click Set.
- Page 7 8. Click Web access. 9. Type in your Password and then click Login. For more information regarding the TPE-224WS configuration and advanced settings, please refer to the User's Guide included on the Utility CD-ROM or TRENDnet's website at www.trendnet.com English...
-
Page 8: Troubleshooting
The default IP Address of the TPE-224WS is "admin". When I access the TPE-224WS using a web browser, I get a screen that tells me “only one user can login”. What should I do? Another computer is configuring the TPE-224WS. Please wait until the user logs off. If the... - Page 9 Return Material Authorization (RMA) number, accompanied by a copy of the dated proof of the purchase. Products returned to TRENDnet must be pre- authorized by TRENDnet with RMA number marked on the outside of the package, and...
- Page 10 ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF TRENDNET’S PRODUCTS. TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S...
- Page 11 English/Espanol - 24/7 Francais/Deutsch - 11am-8pm, Monday - Friday MET Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com 3135 Kashiwa Street Torrance, CA 90505 Copyright ©2006. All Rights Reserved. TRENDnet.
