Specifications

Specifications Specifications
1.2 1.2 Specifications Specifications
* For barebone system, it may not contain CPU, memory, HDD or ODD.
Processor Support Intel
Chipset Mobile Intel
Memory Support DDR3 1066MHz,
2 x SO-DIMM slots, maximun up to 8GB
Display NVIDIA
NVIDIA
HDD Support 2.5" SATA HDD
ODD BD Combo or DVD Super Multi
Front I/O 2 x USB 3.0, 1 x MIC, 1 x Head phone,
4-in-1 Card reader (MMC/SD/MS/MS Pro)
Rear I/O 1 x HDMI, 1 x DVI-I (Dual-Link), 5 x USB 2.0, 1 x S/PDIF,
1 x eSATAII
Audio 7.1 Ch HD Audio with THX TruStudio Pro
LAN Gigabit LAN
WiFi 802.11b/g/n wireless LAN (300Mbps)
Remote Support MCE function
Controller
Power 90W/19V Adapter
Dimension 200mm(W)x70mm(H)x200m(L)
Volume (liters) 2.8L
*1
Due to WinXP and PCH chipset (HM55) limitations, if you use WinXP, please disable the
BIOS option "USB2.0 Rate Matching Hub" to make USB devices work properly.
(For example, in the process of installing WinXP or using USB3.0 devices.)
*2
For eSATA function, Hot Plug function is supported in AHCI mode only. IDE mode does
not support Hot Plug function.
*3
This USB3.0 port does not support Hot-Plug and legacy function. If you wish to use Hot-Plug
USB3.0 device, we suggest you to use it on the front USB3.0 ports.
WARNING
Please realize that there is a certain risk involved with overclocking, including adjusting
the setting in the BIOS, or using the third-party overclocking tools. Overclocking may
affect your system stability, or even cause damage to the components and devices
of your system. It should be done at your own risk and expense. We are not
responsible for possible damage caused by overclocking.
8 8 8 8 8
® TM
Core i3/i5/i7 Mobile Processor
®
HM55 Express chipset
® GeForce GT425M Graphics,
® 3D Vision capable
*2 *3
, 1 x USB3.0
*1
TM
