9.4.1 CPU Configuration

9.4.1 9.4.1 9.4.1 9.4.1 CPU Configuration CPU Configuration CPU Configuration CPU Configuration
Advanced
Configure advanded CPU settings
Intel (R) Core (TM) i5 CPU
Frequency :3.00GHz
Cache L1 :128 KB
Cache L2 :512 KB
Cache L3 :3072 KB
Ratio Status:Unlocked (Min:9, Max:18)
Ratio Actual Value:18
CPU Ratio Setting
Enhanced Halt State (C1E)
Intel (R) Virtualization Tech
CPU Thermal Throttling
No-Excute Memory Protection
Hyper Threading Technology
Active Processor Cores
A20M
Intel (R) SpeedStep (tm) tech
Intel (R) C-STATE tech
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
CPU Ratio Setting
If the ratio status is unlocked, you will find this item appear to allow you
changing the ratio value of this motherboard.
Enhance Halt State (C1E)
All processors support the Halt State (C1). The C1 state is supported
through the native processor instructions HLT and MWAIT and requires no
hardware support from the chipset. In the C1 power state, the processor
maintains the context of the system caches.
Intel (R) Virtualization Tech
When this option is set to [Enabled], a VMM (Virtual Machine Architecture)
can utilize the additional hardware capabilities provided by Vanderpool
Technology.
CPU Thermal Throttling
You may select [Enabled] to enable CPU internal thermal control mechanism
to keep the CPU from overheated.
No-Excute Memory Protection
No-Execution (NX) Memory Protection Technology is an enhancement to
the IA-32 Intel Architecture. An IA-32 processor with "No Execute (NX)
Memory Protection" can prevent data pages from being used by malicious
software to execute code.
Hyper Threading Technology
To enable this feature, it requires a computer system with an Intel
sor that supports Hyper-Threading technology and an operating system
that includes optimization for this technology, such as Microsoft
®
dows XP / Vista
Vista TM / 7, or Linux kernel version 2.4.18 or higher.
