9.4.2 Chipset Configuration

Chipset Configuration Chipset Configuration Chipset Configuration
9.4.2 9.4.2 Chipset Configuration
BIOS SETUP UTILITY
Advanced
Chipset Settings
Share Memory
[Auto]
Onboard HD Audio
OnBoard Lan
Dr. LAN
Link speed : 0 Mbps
Energy Efficient Ethernet
Onboard Card Reader
Legacy Support
Intel VT-d Configuration
MXM Thermal Support
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Share Memory
This allows you to set share memory feature. The default value is [Auto].
Configuration options: [Auto], [32MB], [64MB] and [128MB].
Onboard HD Audio
This allows you to enable or disable the onboard HD Audio feature.
OnBoard Lan
This allows you to enable or disable the onboard Lan feature.
Dr. LAN
This allows you to select "LAN Cable Detection" function.
Energy Efficient Ethernet
This allows you to enable or disable Energy Efficient Ethernet. The default
value is [Disabled].
Onboard Card Reader
This allows you to enable or disable the onboard card reader.
Legacy Support
This allows you to enable or disable the onboard card reader legacy function.
Intel VT-d Configuration
Use this to enable or disable Intel
Technology for Directed I/O). The default value of this feature is [Disabled].
MXM Thermal Support
This allows you to enable or disable the onboard MXM device thermal
feature.
[Enabled]
[Enabled]
[Disabled]
[Enabled]
[Disabled]
Select Screen Select Screen
Select Item Select Item
[Auto]
+- +- Change Option Change Option
F1 F1 General Help General Help
F9 F9 Load Defaults Load Defaults
F10 F10 Save and Exit Save and Exit
ESC ESC Exit Exit
® VT-d technology (Intel ® Virtualization
