9.4.5 USB Configuration

9.4.5 9.4.5 9.4.5 9.4.5 USB Configuration USB Configuration USB Configuration USB Configuration
Advanced
USB Configuration
Legacy USB Support
USB 2.0 Rate Matching hub
Front Onboard USB3
Back Onboard USB3
USB Keyboard/Remote Power On
USB Mouse Power On
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Legacy USB Support
Use this option to select legacy support for USB devices. There are four
configuration options: [Enabled], [Auto], [Disabled] and [BIOS Setup
Only]. The default value is [Enabled]. Please refer to below descriptions
for the details of these four options:
[Enabled] - Enables support for legacy USB.
[Auto] - Enables legacy support if USB devices are connected.
[Disabled] - USB devices are not allowed to use under legacy OS and
BIOS setup when [Disabled] is selected. If you have USB compatibility
issue, it is recommended to select [Disabled] to enter OS.
[BIOS Setup Only] - USB devices are allowed to use only under BIOS
setup and Windows / Linux OS.
USB 2.0 Rate Matching hub
Use this item to enable or disable the USB 2.0 Rate Matching hub.
Due to WinXP and PCH chipset (HM55) limitations, if you use
WinXP, please disable the BIOS option "USB2.0 Rate Matching
Hub" to make USB devices work properly. (For example, in the
process of installing WinXP or using USB3.0 devices.)
Front Onboard USB3
Use this item to enable or disable the use of front USB3 controller.
Back Onboard USB3
Use this item to enable or disable the use of rear USB3 controller.
USB Keyboard/Remote Power On
Use this item to enable or disable USB Keyboard/Remote Power On on the
system.
USB Mouse Power On
Use this item to enable or disable USB Mouse Power On on the system.
4 6 4 6 4 6
4 6 4 6
BIOS SETUP UTILITY
To enable or disable
the onboard USB
controllers.
[Enabled]
[Enabled]
[Enabled]
[Enabled]
[Disabled]
[Disabled]
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
