Navigation Keys; Main Screen - ASROCK VISION 3D SERIES User Manual

9.1.2

9.1.2 Navigation Keys

9.1.2 Navigation Keys Navigation Keys Navigation Keys
9.1.2 9.1.2 Navigation Keys
Please check the following table for the function description of each navigation
key.
Navigation Key(s)
/
/
+ / -
<Enter>
<F1>
<F9>
<F10>
<ESC>
9.2

9.2 Main Screen

9.2 Main Screen Main Screen Main Screen
9.2 9.2 Main Screen
When you enter the BIOS SETUP UTILITY, the Main screen will appear and display
the system overview
BIOS SETUP UTILITY
OC Tweaker Advanced
Main
System Overview
System Time
System Date
BIOS Version
: HM55-MXM P1.00
Processor Type : Intel (R) Core (TM) i5 CPU
M 520 @ 2.40GHz (64bit)
Processor Speed : 3004MHz
Microcode Update
: 20655/2
Cache Size
: 3072KB
Total Memory
: 4096MB
Dual-Channel Memory Mode
DDR3_1
: 2048MB/501MHz DDR3_1002
DDR3_2 : 2048MB/501MHz DDR3_1002
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
System Time [Hour:Minute:Second]
Use this item to specify the system time.
System Date [Day Month/Date/Year]
Use this item to specify the system date.
Function Description
Moves cursor left or right to select Screens
Moves cursor up or down to select items
To change option for the selected items
To bring up the selected screen
To display the General Help Screen
To load optimal default values for all the settings
To save changes and exit the BIOS SETUP UTILITY
To jump to the Exit Screen or exit the current screen
H/W Monitor Boot Security
Use [Enter], [TAB]
or [SHIFT-TAB] to
[ :00:09] 14
select a field.
[Fri 09/03/2010]
Use [+] or [-] to
configure system Time.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Exit
