Vulcan-Hart VECTS12 Specifications

SPECIFICATIONS:
Electric tilting braising pan, Vulcan-Hart Model No. VECTS12.
Stainless steel front and sides. 10 gauge polished stainless
steel pan body with coved interior corners. Formed pouring lip.
The pan pivots on trunnions. Pan can be fully tilted. Solid
sheathed tubular heating elements embedded in 1
aluminum castings affixed to pan bottom for even heat distri-
bution. Elements shut off when pan is tilted 5°. Faucet Bracket.
Controls include a snap acting thermostat adjustable from
160° to 450°F. Requires a 208 or 240 volt, 60 Hz, 1 or 3 phase
power supply.
Exterior dimensions: 29"w x 26"d x 20" overall height; with
handle 33 1 / "h.
4
NSF listed. U L listed.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-31687 (12-01)
1 / " thick
2
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL VECTS12
ELECTRIC TILTING BRAISING PAN
STANDARD FEATURES
Stainless steel front and sides. 10 gauge polished stainless
steel pan body with coved interior corners. Formed pouring
lip.
The pan pivots on trunnions. Pan can be fully tilted.
Solid sheathed tubular heating elements imbedded in 1
thick aluminum castings affixed to pan bottom for even heat
distribution. Elements shut off when pan is tilted 5°.
Faucet bracket.
Controls include a snap acting thermostat adjustable from
160° to 450°F.
Requires a 208 or 240 volt, 60 Hz, 1 or 3 phase power
supply.
One year limited parts and labor warranty.
OPTIONS
Etched gallon markings.
Correction facility package:
- Control cover (lock by others).
- Security type tamper resistant fasteners with tack welds.
480 volt, 50 Hz, 3 phase, includes stepdown transformer
Second year extended limited parts and labor warranty.
ACCESSORIES
12" swing faucet, single temperature.
12" swing faucet, dual temperature.
18" swing faucet, single temperature.
18" swing faucet, dual temperature.
Steaming pan insert rack to hold 12" x 20" food pan.
Lift off cover.
VSKT stand see spec sheet F-32474.
C.S.I. Section 11420
1 / "
2
