ELECTRIC AND
GAS BRAISING PANS
MODELS
VG30
ML-126847
VG40
ML-126848
VE30
ML-126849
VE40
ML-126850
For additional information on Vulcan-Hart Company or to locate an authorized
parts and service provider in your area, visit our website at www.vulcanhart.com
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM

REPLACEMENT PARTS

P.O. BOX 696, LOUISVILLE, KY 40201-0696
CATALOG OF
TEL. (800) 814-2028
FORM 31232 Rev. A (09-06)

Advertisement

Table of Contents
loading

Related Manuals for Vulcan-Hart VE30

Summary of Contents for Vulcan-Hart VE30

  • Page 1: Replacement Parts

    VG40 ML-126848 VE30 ML-126849 VE40 ML-126850 For additional information on Vulcan-Hart Company or to locate an authorized parts and service provider in your area, visit our website at www.vulcanhart.com VULCAN-HART DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC WWW.VULCANHART.COM CATALOG OF REPLACEMENT PARTS P.O.

  • Page 2: Table Of Contents

    Table of Contents Page Description Control Panel Power Box – Gas (ML-126847 & ML-126848) Power Boxes – Electric (ML-126849 & ML-126850) Lid Assembly Lid Bearing (Right Side) Lid Bearing (Left Side) Panels Pan and Lift Unit Heating Elements (ML-126849 & ML-126850) Gas Burners (ML-126847 &...

  • Page 3: Control Panel

    ILLUS. PART NO. PL-56598 00-854817-00001 Box – Control ... 1 00-854534-00001 Board – Temperature ... 1 00-854664-00003 Gasket – Control Panel ... 1 00-854814-00001 Panel – Control Weldment (Short) ... 1 00-854814-00002 Panel – Control Weldment (Long) ... 1 00-854661-00001 Overlay – Control Panel (Manual) ... 1 00-854661-00002 Overlay –...

  • Page 4: Power Box - Gas (Ml-126847 & Ml-126848)

    BRAISING PAN REPLACEMENT PARTS POWER BOX – GAS (ML-126847 & ML-126848) - 4 -...
  • Page 5 ILLUS. PART NO. PL-56599 00-854633-00001 Box – Power (Weldment) ... 1 00-853781-00001 Standoff ... 4 00-854637-00001 Cover – Power Box (Gas) ... 1 00-854635-00001 Panel – Component ... 1 00-417980-00001 Module – Ignitor ... 1 00-411500-00012 Transformer (120:24) ... 1 00-854671-00001 Controller –...

  • Page 6: Power Boxes - Electric (Ml-126849 & Ml-126850)

    BRAISING PAN REPLACEMENT PARTS POWER BOXES – ELECTRIC (ML-126849 & ML-126850) - 6 -...
  • Page 7 ILLUS. PART NO. PL-56644 00-854609-00001 Lid – Power Box ... 1 00-854664-00001 Gasket – Power Box ... 1 00-854707-00002 Terminal Block (2 Pole) ... 1 00-411500-00012 Transformer (120:24) ... 1 00-840115 Contactor (25 Amp.) ... 2/3 00-854554-00001 Panel – Weldment ... 1 00-854607-00001 Box –...

  • Page 8: Lid Assembly

    BRAISING PAN REPLACEMENT PARTS LID ASSEMBLY - 8 -...
  • Page 9 ILLUS. PART NO. PL-56606 00-854573-00001 Handle – Lid (30 Gallon) ... 1 00-854573-00002 Handle – Lid (40 Gallon) ... 1 SC-023-23 Mach. Screw 00-854578-00001 Lid Weldment (W/O Vent) (30 Gallon) ... 1 00-854578-00002 Lid Weldment (W/Vent) (30 Gallon) ... 1 00-854579-00001 Lid Weldment (W/O Vent) (40 Gallon) ...

  • Page 10: Lid Bearing (Right Side)

    BRAISING PAN REPLACEMENT PARTS LID BEARING (RIGHT SIDE) - 10 -...
  • Page 11 ILLUS. PART NO. PL-56605 00-854567-00001 Bearing – Lid ... 3 00-854562-00001 Housing – Lid Bearing ... 1 00-854565-00001 Lock Nut – Lid Spring ... 1 00-854558-00001 Lid – Bearing Cover ... 1 00-854569-00001 Spring – Torsion (RH) ... 1 00-854564-00001 Retainer – Lid Spring ... 1 KW-003-04 Key –...

  • Page 12: Lid Bearing (Left Side)

    BRAISING PAN REPLACEMENT PARTS LID BEARING (LEFT SIDE) - 12 -...
  • Page 13 ILLUS. PART NO. PL-56604 00-854561-00001 Mandrel – Lid Spring ... 1 00-854567-00001 Bearing – Lid ... 3 00-854639-00001 Housing Assy. – Lid Bearing ... 1 KW-003-04 Key – Woodruff ... 1 00-854564-00001 Retainer – Lid Spring ... 1 00-854569-00002 Spring – Torsion (LH) ... 1 00-854558-00001 Lid –...

  • Page 14: Panels

    BRAISING PAN REPLACEMENT PARTS PANELS - 14 -...
  • Page 15 ILLUS. PART NO. PL-56603 00-854550-00001 Flue Assy. (30 Gallon) (ML-126847) ... 1 00-854555-00001 Flue Assy. (40 Gallon) (ML-126848) ... 1 00-854546-00001 Back Splash Assy. (30 Gallon) ... 1 00-854547-00001 Back Splash Assy. (40 Gallon) ... 1 00-854585-00002 Panel – Back (30 Gallon) ... 1 00-854585-00003 Panel –...

  • Page 16: Pan And Lift Unit

    BRAISING PAN REPLACEMENT PARTS PAN AND LIFT UNIT - 16 -...
  • Page 17 ILLUS. PART NO. PL-56602 00-854519-00001 Gear – Reducer ... 1 00-854648-00001 Extension – Gear Reducer Shaft ... 1 RP-002-46 Roll Pin 00-854652-00001 Shaft – Handle ... 1 00-854651-00001 Handle – Crank ... 1 00-854600-00002 Pan – Braising (ML-126847) ... 1 00-854641-00002 Pan –...

  • Page 18: Heating Elements (Ml-126849 & Ml-126850)

    BRAISING PAN REPLACEMENT PARTS HEATING ELEMENTS (ML-126849 & ML-126850) - 18 -...
  • Page 19 ILLUS. PART NO. PL-56645 00-854511-00001 Element – Heating (240 V.) ... 3/4 00-854511-00002 Element – Heating (480 V.) ... 3/4 00-854509-00001 Clamp – Heater ... 12/16 00-854542-00001 Cover – Insulation (30 Gallon) ... 1 00-854542-00002 Cover – Insulation (40 Gallon) ... 1 00-854544-00001 Cover –...

  • Page 20: Gas Burners (Ml-126847 & Ml-126848)

    BRAISING PAN REPLACEMENT PARTS GAS BURNERS (ML-126847 & ML-126848) - 20 -...
  • Page 21 ILLUS. PART NO. PL-56600 00-854592-00001 Flue – Transition Plate (30 Gallon) ... 1 00-854627-00001 Flue – Transition Plate (40 Gallon) ... 1 00-840144 Burner – Air Shutter Assy..3/4 00-854593-00001 Cover – Insulation ... 2 00-854830-00001 Clamp – Runner Tube ... 2 00-854594-00001 Bracket –...

  • Page 22: Gas Piping (Ml-126847 & Ml-126848)

    BRAISING PAN REPLACEMENT PARTS GAS PIPING - 22 -...
  • Page 23 ILLUS. PART NO. PL-56601 FP-077-47 Pipe FP-013-22 Elbow Pipe FP-036-06 Pipe 00-844133-00001 Valve – Combination (Nat) ... 1 00-844133-00002 Valve – Combination (LP) ... 1 FP-036-92 Pipe FP-036-98 Pipe FP-083-52 Pipe FP-059-65 Pipe FP-022-17 Union – Pipe ... 1 FP-012-21 Fitting 00-840096-00039 Fitting –...

  • Page 24: Draw Off Valve Parts

    BRAISING PAN REPLACEMENT PARTS 2” TANGENT DRAW-OFF VALVE PARTS PART NO. NAME OF PART AMT. 00-854605-00002 Valve Body ... 1 00-854605-00003 O-Ring ... 1 00-854605-00004 Disc & Stem Assy..1 00-854605-00005 Bonnet ... 1 00-854605-00006 Hex Nut ... 1 00-854605-00007 Handle ...

  • Page 25: Recommended Spare Parts

    00-854717-00001 Up Limit Micro Switch ... 1 00-855036-00001 Transformer (240/480/120) (150VA) ... 1 00-854653-00001 Gear Motor ... 1 00-411496-000F1 Lid Micro Switch (Auto-Lift) ... 2 (VG30 & VG40) NAME OF PART (VE30 & VE40) NAME OF PART - 25 - AMT. AMT.

This manual is also suitable for:

Ve40Vg30Vg40
